Most innovative companies for 01/25/2022 (new inventions)
Exciting new inventions from The Boeing Company, Mitsubishi Electric Corporation, Hyundai Motor Company, Ricoh Company, Ltd. And Kubota Corporation
This is a weekly article summarizing a handful of inventions from the most innovative companies in the world. The summaries are created by an A.I. and proof-read by a human before publication. Attempts are made to ensure accuracy of the descriptions, but it is very much a work in progress. Each invention description is preceeded by a poem about the invention that is written by the A.I. I have found the limerick is actually quite good at explaining the invention in simple terms. Enjoy!
The Boeing Company
A Method of Making a Test Coupon Using a Mold - Provides Precise Control Over Grip and Runner Size
What is this invention?
Monolithic precursor test coupons for testing material properties of metal-injection-molded components and methods and apparatuses for making such coupons
A method to make a test coupon we've found,
With a mold that has many cavities around.
Feedstock material is injected with great care,
To form a monolithic precursor test coupon there.
The runners are then removed without any fuss,
Leaving behind a grip portion for each of us.
Do you ever find yourself wishing you could test a new material before you invest in it? Well, with this amazing innovation from The Boeing Company, that wish may soon become a reality. The monolithic precursor test coupons offered by this company are perfect for testing the properties of metal-injection-molded components before you put them into production. This process begins by injecting feedstock material into the mold cavity, which will result in the formation of a monolithic test coupon. Once this is complete, the runners on the coupon will need to be removed in order to get an accurate representation of how the final product will behave. This technology has huge potential and could revolutionize the way we approach component testing!
A method of making a test coupon using a mold is provided. The mold defines a mold cavity that comprises a first-grip-portion cavity, a second-grip-portion cavity, an intermediate-portion cavity, interconnecting the first-grip-portion cavity and the second-grip-portion cavity, and runner cavities, directly interconnecting the first-grip-portion cavity and the second-grip-portion cavity and not directly connected to the intermediate-portion cavity. The method comprises injecting feedstock material, comprising a metal powder, into the mold cavity to form a monolithic precursor test coupon in the mold cavitiy. The monolithic precursor test coupon comprises a first grip portion, a second grip portion, an intermediate portion, and runners. The method also comprises removing the runners from the monolithic precursor test coupon.
US Patent 11229951
MITSUBISHI ELECTRIC CORPORATION
Numerical Control Keeps Workpiece High in Additive Manufacturing Process
What is this invention?
Numerical control device, additive manufacturing apparatus, and method for controlling additive manufacturing apparatus
There once was a machine called NC,
Which could detect any height error.
It would then adjust the flow,
So that the workpiece would be just right.
This made everyone in the shop quite happy,
Since it meant fewer things went awry.
Additive manufacturing is a growing industry that has the potential to revolutionize many aspects of manufacturing. One such area that could see significant change is the way models are created. Traditional 3D printing uses a layer-by-layer process to create objects from plastic or other materials. However, this method has several limitations, the most notable of which is the inability to create complex shapes and structures. Additive manufacturing uses computers to control a machine that irradiates a wire with a beam of light in order to deposit material on top of it. This technology has already proven itself capable of creating high-quality objects, but there are still some areas where it can be improved. One such area is accuracy - currently, additive manufacturing machines are very good at depositing material close to where they were aimed, but they can often miss small details nearby. The error detecting unit in the numerical control device described in this article helps solve this problem by automatically adjusting the supply amount of material based on how accurate the machine is performing. By doing so, you can ensure that your final product will be accurate and consistent from one print job to another.
The numerical control device includes an error detecting unit that detects an error in the height of the workpiece in the height direction in which the material is deposited. The numerical control device then adjusts the supply amount of material on the basis of this detected error.
US Patent 11229956
Hyundai Motor Company
New Injection Molding Apparatus for Stiffeners with Unpredictable Size
What is this invention?
Injection molding apparatus for inserting atypical stiffener
The injection molding apparatus has an upper and under mold,
With an upper core and under core respectively held.
The elastic clampers are supported by the under mold,
And serve to keep the atypical stiffener in place.
When the synthetic resin melt is introduced, it'll be correctly positioned between the two cores - what a great feat!
If you're looking for an innovative way to improve your injection molding process, you'll want to check out the Hyundai Motor Company injection molding apparatus. This system includes elastic clampers that are supported by the under mold and embedded in the under core of the machine. When synthetic resin melt is introduced, these clamps pressurize both sides of the atypical stiffener to ensure that it is held in place during manufacturing. This can save time and help reduce errors during production. If you're looking for a new and improved way to manufacture your products, this is one option that you won't want to miss out on!
The injection molding apparatus includes an upper mold and an under mold. The upper mold has an upper core and the under mold has an under core. The elastic clampers are supported by the under mold, embedded in the under core, interlocked with the size of the atypical stiffener, and elastically pressurizing both sides to hold the atypical stiffener to be inserted into a correct position between the upper core and the under core by the atypical stiffener when the synthetic resin melt is introduced.
US Patent 11230038
THE BOEING COMPANY
Additive Manufacturing System Fuses Build Medium to Create Objects
What is this invention?
Additive manufacturing using light source arrays to provide multiple light beams to a build medium via a rotatable reflector
There once was a machine for making things
With a print head and two light source arrays
The controller could make the beams fuse
To build objects from the medium they were using
Additive manufacturing at its best!
Additive manufacturing is a process of creating physical objects by depositing material layer by layer using a 3D printer. One of the most common materials used in additive manufacturing is plastic. However, many printers are not able to print with high quality plastics due to the fact that they use only one light source to create the object. This single light source can cause defects in the finished product because it does not allow for layers of plastic to be fused together correctly.The Boeing Company has developed an innovative additive manufacturing system that uses multiple light sources to provide better results when printing with plastic. The system includes a print head, two light source arrays, and a controller. The print head includes two rotatable reflectors - one for directing first light beams towards the build medium and another for directing second light beams towards the build medium. The first light source array is configured to direct multiple first light beams towards the build medium via the first rotatable reflector while the second light source array is configured to direct multiple second light beams towards the build medium via the second rotatable reflector. Together, these two arrays provide enough different types of lighting so that layers of plastic can be properly fused together and form objects from the build medium.This type of system has many benefits over traditional additive manufacturing systems because it allows for higher quality prints with fewer defects. Not only does this improve how products look on paper, but it also reduces costs and time spent making corrections during production.
An additive manufacturing system includes a print head, a first light source array, and a second light source array. The print head includes a first rotatable reflector and a second rotatable reflector. The first light source array is configured to direct multiple first light beams toward the build medium via the first rotatable reflector. The second light source array is configured to direct multiple second light beams toward the build medium via the second rotatable reflector. The controller is coupled to the print head, the first light source array, and the second light source array. The controller is configured to control activation of the first light beams and activation of the second light beams to selectively fuse portions of the build medium to form one or more objects from the build medium
US Patent 11230058
The Boeing Company
Induction Welding a First and Second Carbon Fiber Thermoplastic Composites
What is this invention?
Induction welding using a heat sink and/or cooling
There once was a way to weld two plastics
With an induction coil and some heat
But if you wanted the joint to be strong
You had to first flex on a heat sink
Induction welding is a process that has been around for many years, but there have always been some limitations. One of the main problems with induction welding has been the difficulty in joining two carbon fiber thermoplastic composites (TPCs). With this new innovation from The Boeing Company, however, this problem may finally be solved! In this process, you first align the TPCs so that they form a weld interface area. Then, you flex a heat sink onto this area and apply an induction coil to heat it up. This will cause the two TPCs to fuse together and create a strong joint! This technology could revolutionize the way we do inductive heating on large pieces of metal. We are sure that other companies will soon follow suit and bring even more innovative products to market!
The patent describes a method of induction welding two carbon fiber thermoplastic composites using an induction coil. First, the two composites are aligned so that a weld interface area is formed. A heat sink is then flexed onto the surface of one of the composites between the weld interface area and the induction coil, and the induction coil is used to heat up the weld interface area.
US Patent 11230066
RICOH COMPANY, LTD.
New Liquid Discharge Head Enhances Efficiency
What is this invention?
Liquid discharge head, discharge device, and liquid discharge apparatus
There once was a liquid discharge head
That included a nozzle plate and channel bed
A common channel substrate
And a wall member with deformable region--
So the pressure could be better instead!
RICOH COMPANY, LTD. has released a new liquid discharge head that is sure to revolutionize the way you operate your vehicle's tow system! The nozzle plate includes a plurality of nozzles that are configured to discharge liquid at high pressure. This allows for quick and efficient liquid discharge, which in turn helps to improve fuel efficiency and overall performance. Additionally, the channel plate includes a plurality of pressure chambers that are communicated with the nozzles, respectively. This ensures even distribution of the discharged liquid throughout the entire system. Finally, the common channel substrate includes a common channel that is communicatively linked with all of the pressure chambers. This prevents any one chamber from becoming overloaded and causing damage to other components within the system. Overall, this innovative product represents great progress in improving tow vehicle performance and reliability!
A liquid discharge head includes a nozzle plate, a channel plate, a common channel substrate, and a wall member. The nozzle plate includes a plurality of nozzles configured to discharge liquid. The channel plate includes a plurality of pressure chambers communicated with the nozzles, respectively. The common channel substrate includes a common channel communicated with the pressure chambers. The wall member includes a deformable region in a part of a wall surface of the common channel. The channel plate and the common channel substrate are disposed with the wall member interposed between the channel plate and the common channel substrate. Thechannel plate includes an air chamber facing the deformable region. The bridge portion partially divides the air chamber in nozzle arrangement direction in which nozzles are arranged. The bridge portion is not in contact with wall member and nozzleplate
US Patent 11230102
Ricoh Company, Ltd.
Liquid Discharge Apparatus with Upper Limit Detectors That Detect Different Amounts Left in Sub Tanks
What is this invention?
Liquid discharge apparatus
There once was a liquid discharge apparatus
With a plurality of head units configured to discharge a liquid
And a plurality of sub tanks configured to store the liquid being supplied
To the head units, with at least two upper limit detectors per sub tank
Detecting different upper limits for the remaining amount of liquid
Looking for a liquid discharge apparatus that can handle a lot of pressure? Look no further than the Ricoh Company, Ltd. Liquid discharge apparatus! This versatile machine is capable of discharging a variety of liquids, including but not limited to gasoline, diesel fuel, and water. In addition to its high-pressure capabilities, the Ricoh also has a number of other features that make it an ideal choice for businesses and industrial applications. For example, each head unit is individually controlled so that you can precisely deliver your liquid solution without any wasted product or spilled fluid. Additionally, the system has a built-in safety feature that monitors the remaining amount of liquid in each sub tank - ensuring that there are never any shortages or overages onsite. If you're looking for an efficient and reliable liquid discharge apparatus - look no further than the Ricoh!
A liquid discharge apparatus includes a plurality of head units configured to discharge a liquid, a plurality of sub tanks configured to respectively store the liquid to be supplied to the plurality of head units, and a plurality of upper limit detectors configured to respectively detect upper limits of remaining amounts of liquid in the plurality of sub tanks. At least two of the plurality of upper limit detectors of corresponding at least two of the plurality of sub tanks detect different upper limits of the remaining amounts of liquid in the at least twoof the pluralityof sub tanks.
US Patent 11230113
RICOH COMPANY, LTD.
Liquid Discharge Apparatus Provides Controlled Illumination for Curing Liquid
What is this invention?
Liquid discharge apparatus, liquid discharge method, and non-transitory recording medium
There once was a liquid discharge device
That could shoot out a curable liquid with great precision
It had an irradiator to cure the surface
And a carriage to move in any direction
This amazing invention ensured that every discharge was perfect!
Looking for a way to improve your liquid discharge process? Look no further than the RICOH COMPANY, LTD. Liquid Discharge Apparatus! This innovative device allows you to irradiate your discharge target with active-energy rays to create a durable liquid discharge surface. The carriage can then be moved in both the main-scanning and sub-scanning directions to ensure even exposure of the entire surface. Additionally, illuminance of the active-energy rays can be controlled according to length of the discharge range on the target - ensuring accurate results every time. Whether you're looking for an efficient liquid discharge system or just want to improve your process overall, this is definitely one product worth considering!
The patent describes a liquid discharge apparatus that includes a discharge device configured to discharge a liquid curable by active-energy rays onto a discharge target to form a liquid discharge surface, an irradiator configured to irradiate the liquid discharge surface with the active-energy rays, and a carriage mounting the discharge device and the irradiator. The carriage is configured to move in the main-scanning direction, and the circuitry is configured to relatively move the carriage and the discharge target in the main-scanning direction, relatively move the carriage and the discharge target in a sub-scanning direction perpendicular to the main-scanning direction, and control illuminance of the active-energy rays emitted from the irradiator to the liquid discharge surface on the discharge target according to length of a discharge range of the liquid discharge surface on the discharge target in the main-scanning direction.
US Patent 11230119
HYUNDAI MOTOR COMPANY
A Battery System Keeps Your Vehicle Running Smoothly
What is this invention?
Battery system of vehicle
There was a car with a battery system
That used a BMA for its power mechanism
The cooling fan was aligned
To keep the BMA cooled and fine
And the low voltage battery was on the other side
The battery system of a vehicle is an important part of any electric vehicle. It allows the vehicle to be powered by a single source of energy, rather than relying on multiple sources like gasoline or diesel engines. In this article, we will take a look at the HYUNDAI MOTOR COMPANY battery system. This system includes a battery module assembly (BMA) formed by overlapping a plurality of battery modules along a first direction, a cooling fan installed to be aligned along the first direction on one side of the BMA and configured to discharge air cooling the BMA while passing therethrough, a low voltage battery installed to be aligned along the first direction on the other side of the BMA, a power relay assembly (PRA) aligned along a second direction perpendicular to the first direction and installed adjacent to the low voltage battery, and a battery management system (BMS) aligned along a third direction perpendicular to the first direction and the second direction and installed adjacent to the low voltage battery and PRA. The BMS is responsible for monitoring all aspects of your batteries - from charging rates to temperature readings. By keeping everything in check, you can rest assured that your batteries are performing at their best.
The battery system of a vehicle includes a battery module assembly (BMA) formed by overlapping a plurality of battery modules along a first direction, a cooling fan installed to be aligned along the first direction on one side of the BMA and configured to discharge air cooling the BMA while passing therethrough, a low voltage battery installed to be aligned along the first direction on the other side of the BMA, a power relay assembly (PRA) aligned along a second direction perpendicular to the first direction and installed adjacent to the low voltage battery, and a battery management system (BMS) aligned along a third direction perpendicular to the first direction and the second direction and installed adjacent to the low voltage battery and PRA.
US Patent 11230177
Hyundai Motor Company
New Engine Mount Allows for Customizable Amplitude Properties
What is this invention?
Engine mount
There once was an engine mount
That could change based on input amplitude.
It included a membrane with central and outer portions,
And upper and lower orifice brackets to divide the main casing into chambers.
The flow path between the chambers allowed fluid to move,
And the air chamber exposed a lower portion of the membrane to air.
Do you ever find yourself wishing that your engine mount could do a little more? Well, Hyundai has come up with a solution for just that! Their engine mount is designed to dynamically change properties based on the magnitude of amplitudes input to it. This means that it can handle a lot more power than traditional mounts, without sacrificing stability or durability. In addition, the air chamber connected to the lower side of the lower orifice bracket allows for greater exposure of the membrane to air - which helps increase performance and fuel efficiency. If you're looking for an upgrade that will make your vehicle stand out from the rest, look no further than this innovative engine mount from Hyundai!
The engine mount is designed to change properties based on amplitudes input. The engine mount includes a membrane with a central portion and an outer circumferential portion. Upper and lower orifice brackets are mounted between an insulator and a diaphragm to divide an interior of the main casing into an upper liquid chamber and a lower liquid chamber. The upper and lower orifice brackets define a flow path that enables fluid to flow between the upper and lower chambers, as well as defining a receiving space in which the membrane is movable in a vertical direction. An air chamber is connected to the lower side of the lower orifice bracket, allowing a lower portion of the membrane to be exposed to air.
US Patent 11230178
Kubota Corporation
Work Vehicle with Cooling Water Circulation Hose for Engine Cooling
What is this invention?
Work vehicle
There once was a work vehicle,
With a suspension and engine between.
The left and right link mechanisms
Upper and lower links did sustain,
And a radiator on the outer side cooled it just fine.
Do you work in a hot environment? If so, you know that it is important to keep your engine running as cool as possible. One way to do this is by using a radiator. Radiators are typically located on the outside of a vehicle, near the wheels. However, in some cases it may be difficult or impossible to install a radiator in this location. That's where the Kubota Corporation Work Vehicle comes in! This innovative product includes a pair of left and right link mechanisms that support the wheel support member to be vertically pivotable. This allows for easy installation of a radiator anywhere within reach - even inside of an enclosed space like a car! Not only does this provide extra cooling for your engine, but it also makes repairs much easier since you don't have to remove the entire vehicle paneling!
The work vehicle includes a suspension mechanism disposed between the vehicle body and the wheel support member, and an engine disposed between the pair of left and right link mechanisms. Each one of the pair of left and right link mechanisms includes an upper link provided between a link support portion formed in the vehicle body and the wheel support member and a lower link provided between the link support portion and the wheel support member. The radiator is disposed on lateral outer side of the vehicle body relative to the link mechanisms, and a cooling water circulation hose is connected to the engine and the radiator. The cooling water circulation hose is configured to circulate engine cooling water between the engine and radiator.
US Patent 11230184
KUBOTA CORPORATION
Floor Mat Arranged in a Working Machine Allows for Flexible Connection to Circumferential Portion
What is this invention?
Floor mat and working machine
There once was a floor mat so clever
It made working in the machine much easier
With a body on the floor
And a covering to close the door
This mat was quite simply a life saver!
Do you have a floor mat that you use when working on your machine? If so, you may be interested in this new innovation from KUBOTA CORPORATION. The floor mat is designed to help protect your floor and work surface while you are working. The mat is arranged in a working machine and includes a floor portion, a wall portion arranged on a circumferential portion of the floor portion, and an opening portion arranged on a part of the connecting portion of the wall portion. The connecting portion connects the covering portion flexibly to the circumficial part of the mat main body. This makes it easy to move around while you are working - whether you need to change position or adjust your tools!
The floor mat in this example includes a mat main body arranged on the floor portion, a covering portion configured to cover the opening portion, and an connecting portion configured to connect the covering portion flexibly to a circumferential portion of the mat main body. The floor mat is arranged in a working machine, and includes features that make it easy to attach and remove.
US Patent 11230212
HYUNDAI MOTOR COMPANY
Height-Adjustable Cup Holder - Keep Your Drink Nearby
What is this invention?
Height-adjustable cup holder
There once was a cup holder housing
That included a first and second stand
With a guide member positioned in between
So that a cup holder unit could be fitted on top
And held in place by the two support plates
Do you ever feel like your cup holders just aren't big enough? Well, the folks at Hyundai have come up with a solution for you - the Height-Adjustable Cup Holder! This nifty little gadget allows you to adjust the height of your cup holder in order to better fit whatever beverage or snack you are carrying. Not only is this great for making sure that your beverages stay cold all day long, but it can also accommodate larger snacks and meals without having to worry about them spilling all over yourself or your vehicle. Installation is simple - just unscrew the existing cup holder unit, slide in the new one, and screw it back on. There's no need to modify any of your existing hardware, so installation is quick and easy! Once installed, you'll never have to worry about finding a comfortable position for drinking or eating again. Thanks Hyundai!
US Patent 11230213
Hyundai Motor Company
Vehicle Bottom Monitoring with Forward, Left-Side, Right-Side and Rear Images
What is this invention?
Method and system for monitoring vehicle bottom condition
There once was a method for monitoring
A vehicle's bottom condition.
Forward, left-side, right-side, and rear
Images were received from a camera,
And traveling distance information too.
Then an image of the bottom was generated,
Which was matched with an SVM image.
If there was any issue found,
It could be corrected before further action was taken.
Monitoring your vehicle's bottom condition is important for safety reasons, but it can be a time-consuming task. With this new Hyundai invention, you no longer have to worry about it - thanks to the camera and sensor unit combination. When you receive notification that your vehicle has hit a bump or pothole, the system will automatically start recording forward, left-side, right-side, and rear images. This footage is then processed using travel distance information to generate a bottom image which is compared with surrounding view monitoring (SVM) images of the area. If there are any discrepancies between the two images, an alert will be sent to your phone or computer so that you can take action immediately!
A method is provided for monitoring a vehicle bottom condition. Forward, left-side, right-side, and rear images of the vehicle are received from a camera unit of the vehicle. Traveling distance information of the vehicle is also received from a sensor unit of the vehicle. Images stored based on these inputs are then used to generate a vehicle bottom image. The generated image is then matched with an SVM image of the vehicle to determine if there is any issue with the bottom of the vehicle. If there is an issue, it can be corrected before further action is taken.
US Patent 11230236
Kubota Corporation
A Seatbelt of a Work Vehicle Includes: A First Stay Provided in Correspondence with a First Fixing Portion of a Vehicle Body on Either One of Right/Le
What is this invention?
Work vehicle
There once was a seatbelt for work,
With a first stay on either side of the seat.
The belt reeling portion stored the belt main body,
And the buckle fixed an insertion fixture.
First and second cover members were mounted,
To keep the stays outwardly exposed.
Do you work in a dangerous environment? Are you constantly on the move and need to be able to securely fasten your seatbelt? If so, check out the Kubota Corporation Work Vehicle Seatbelt! This innovative product provides a secure way of restraining yourself while you are working or driving. The seatbelt includes a first stay that is attached to either one of the right/left sides of your seat and a belt reeling portion that stores the belt main body. The belt reeling portion is attached to the first stay via a hinge joint, allowing for easy adjustment and removal. Additionally, there is also a second stay that attaches to the other side of your seat and provides additional stability. Finally, there is a buckle portion that fixes an insertion fixture extending from the belt reeling portion and attaches it to the second stay. This ensures that your seatbelt will be securely fastened even when you are moving around quickly. With this amazing safety device, you can rest assured knowing that you are fully protected during any hazardous activity!
A seatbelt for a work vehicle includes a first stay provided in correspondence with a first fixing portion of the vehicle body on either one of right/left sides of a seat, a belt reeling portion that reels and stores the belt main body, and is attached to the first fixing portion via the first stay. A second stay is provided in correspondence with a second fixing portion on the other one of the right/left sides of the seat, and a buckle portion fixes an insertion fixture extending from the belt reeling portion and is attached to the second fixing portion via the second stay. A first cover member is mounted to the first stay and covers an outward exposed portion of the first stay. A second cover member is mounted to the second stay and covers an outward exposed portion of the second stay.
US Patent 11230256
HYUNDAI MOTOR COMPANY
Integrated Brake System Simplifies Control and Reduces Costs
What is this invention?
Vehicular integrated braking system
There once was a brake system so nifty
It had EBS and EPB--what a gift!
With just one integrated controller,
This design was much neater and cleaner.
Though some pneumatic routes were removed,
The result was still quite cost-effective.
Vehicular integrated braking systems (VICS) are becoming more and more popular as the technology behind them continues to improve. By integrating an EPB valve into an EBS valve system, VICS simplifies brake controller design and reduces costs. This is great news for drivers who want a simple and easy-to-use system that will help them stop quickly in any situation. Not only does this integration reduce the number of parts in your brake system, but it also allows for improved performance due to optimized pneumatic routing. If you're looking for a cost-effective way to upgrade your current braking system, then a VICS may be just what you need!
A vehicular integrated brake system has an EBS and an EPB system integrated in the system to simplify a brake control system and reduce costs. An EBS function and an EPB function are incorporated by adding an EPB valve in the EBS valve system, so that the actuation of the EBS valves and the EPB valve can be controlled by a single integrated controller. A separate pneumatic route connecting the EPB is removed to optimize the pneumatic route. Thus, it is possible to simplify the controller and to reduce costs.
US Patent 11230274
Mitsubishi Electric Corporation
Vehicle Control Device Discloses ETC Toll-Free Travel
What is this invention?
Vehicle control device
The vehicle control device of today
Allows you to pass through the ETC toll gate in your way
With a speed that's just right
So you don't need to fight
For the cruise control unit to obey
Looking for a way to keep your vehicle under control while on the road? Check out this amazing invention from Mitsubishi Electric Corporation! The Vehicle Control Device (VCD) allows you to set a speed and continue traveling at that set speed until the VCD detects that you have passed through an ETC toll gate. Once detected, the VCD will then change control content in your cruise control unit so that you can continue on your journey without any interference. This system is perfect for those times when you need to stay within preset boundaries while on the road - ensuring that you arrive at your destination safely and without delay. If you're looking for a way to improve your driving experience, don't miss out on this incredible innovation!
The vehicle control device disclosed in the present disclosure includes a first control unit configured to control a speed of the vehicle in accordance with the route distance and the set speed until the detection unit determines that the vehicle has passed through the ETC toll gate, while the vehicle is performing the constant-speed traveling by the cruise control unit. The vehicle frontward detecting unit is configured to detect road information about a road frontward of the vehicle, and the second control unit is configured to change control content in the cruise control unit on the basis of a detection result from the vehicle frontward detecting unit, when it is determined that the vehicle has passed through an ETC toll gate.
US Patent 11230287
THE BOEING COMPANY
Wall Assembly for an Interior of an Aircraft Includes Two Decorative Panels
What is this invention?
Interior aircraft frame assembly for furnishings
There was an airplane whose cabin was in need
Of some new interior panels, so the crew did concede.
Two sides were there to be covered with art
So they went and found a frame member to start.
The first decorative panel was then quickly secured
Introducing the Boeing Company's new interior aircraft frame assembly! This wall assembly is perfect for enhancing the look of any aircraft. It is made from sturdy, high-quality materials and includes two decorative panels - one on each side of the frame. Whether you're looking to add a touch of luxury or just want to spruce up your cabin, this frame assembly is sure to please. So why wait? Order yours today!
This text describes a wall assembly for an interior of an aircraft. The frame member is secured within the cabin of the aircraft and has two opposing sides. The first decorative panel is secured to the frame member on one side of the frame, and the second decorative panel is secured to the frame member on the other side of the frame.
US Patent 11230380
The Boeing Company
Duct system powers your home with solar energy
What is this invention?
Aircraft air duct system for transmitting electrical power and visible light
There once was an air duct system
With a reflective inner surface
A visible light source generated light
Which was converted into power by photovoltaic devices
Do you ever find yourself wishing you could power your devices with the sun? Well, now there's a way to do just that! The Boeing Company has developed an air duct system that will allow you to harness the power of the sun. This system is perfect for powering devices such as laptops and cell phones. All you need is an air duct with a reflective inner surface and a visible light source like a flashlight or lamp. Once installed, simply point the light towards the inner surface of the duct and watch as your gadgets get powered up! Not only does this system provide you with clean energy, but it also helps reduce environmental waste by converting sunlight into electrical power. So why wait? Give this innovative technology a try today!
An air duct system comprising an air duct having a main body, a visible light source, and one or more photovoltaic devices. The main body of the air duct defines a passageway having a reflective inner surface. The visible light source is configured to generate visible light, where the visible light source directs the visible light along the reflective inner surface of the air duct. The one or more photovoltaic devices are disposed along the reflective inner surface of the air duct, where a portion of the visible light generated by the visible light source is converted into electrical power by the one or more photovoltaic devices.
US Patent 11230383
MITSUBISHI ELECTRIC CORPORATION
Elevator with Activating Lever to Activate Emergency Gear Prevents Accidents
What is this invention?
Elevator apparatus
The elevator's apparatus has a lever
That activates the emergency gear.
A speed governor mechanism is found,
With a sheave and rope that are wound around.
The activating lever has some resistance,
So the safety gear can be engaged in an instant.
Do you ever find yourself in a situation where you need to activate an emergency safety gear but don't have the time or dexterity to do so? Well, MITSUBISHI ELECTRIC CORPORATION has the solution for you! Their Elevator Apparatus features an activating lever that activates the emergency safety gear automatically. This system is great for elevators that travel at high speeds, as it prevents accidental activation of the gear while in motion. Additionally, this system can be configured to resist movement of the activating lever in any direction - ensuring that activation of the gear is always reliable and safe. Give this innovative product a try next time you find yourself in a sticky situation!
The elevator apparatus has an activating lever that activates the emergency safety gear. A speed governor mechanism is disposed on the emergency safety gear, and includes a speed governor sheave, a tensioning sheave, and a speed governor rope that is wound onto the speed governor sheave and the tensioning sheave. The speed governor rope is connected to the activating lever. A resistance applying mechanism applies a resisting force during ascent of the car against movement of the activating lever in a direction that activates the emergency safety gear.
US Patent 11230457
