Most innovative companies for 03/01/2022 (new inventions)
Exciting new inventions from The Boeing Company, Ford Global Technologies, Llc, Hyundai Motor Company, Honda Motor Co., Ltd. And Canon Kabushiki Kaisha
This is a weekly article summarizing a handful of inventions from the most innovative companies in the world. The summaries are created by an A.I. and proof-read by a human before publication. Attempts are made to ensure accuracy of the descriptions, but it is very much a work in progress. Each invention description is preceeded by a poem about the invention that is written by the A.I. I have found the limerick is actually quite good at explaining the invention in simple terms. Enjoy!
Ford Global Technologies, LLC
Injecting Fuel Through Three Different Rows of Nozzles Delivers Up to Five Shots in One Cycle
What is this invention?
Methods and systems for a fuel injector assembly
There once was an injector named Moe
Who could shoot fuel through three rows
He could deliver five sprays
In one actuation cycle
Making him the best in his shows
In today's world, fuel injection is a critical part of engine operation. With engines becoming more and more powerful, it is important that we find ways to optimize the delivery of fuel to each and every cylinder. One way we've done this in the past is by using multiple rows of injector nozzles - one for each row of cylinders on an engine. But with engines getting larger and more powerful, this approach has started to become less feasible. That's where Ford Global Technologies, LLC.'s new methods and systems come into play.Instead of using multiple rows of injector nozzles, Ford Global Technologies, LLC.'s methods and systems allow for the use of three different vertical planes - or "rows" - of injector nozzles on an injector body. This allows us to deliver up to five injections at once without having to wait between injections. In addition, since each row is located along a different vertical plane, we can maximize the amount of fuel delivered directly to each cylinder without any wasted gas traveling between rows or chambers. This means better performance and fewer emissions from your engine!
Methods and systems are provided for injecting fuel through three different rows of injector nozzles, where each row of the injector nozzle is arranged along a different vertical plane of the injector body. In one example, an injector needle housed movably inside the injector body may supply high-pressure fuel to each of the rows of injector nozzles sequentially to deliver up to five fuel injections in one actuation cycle of the fuel injector.
US Patent 11260407
HYUNDAI MOTOR COMPANY
The Cleaning Device Keeps Your Hemming Roller Running Smoothly
What is this invention?
Cleaning device for hemming roller
There once was a cleaning device
That included a support frame
It was installed on the floor
And rotated the hemming roller
To remove foreign substances and make it clean once more.
Hemming roller units can get pretty dirty over time, and a cleaning device is essential for keeping them in good condition. Hyundai Motor Company has invented a nifty device that includes a support frame and hemming roller rotation unit - all installed on the floor of your workshop. The roller rotation unit rotates the dirty hemming roller as it enters the upper surface of the support frame, and then the scraper is installed to remove any foreign substances on the surface of the hemming roller. This way, you can keep your Hemming Roller clean and functioning at its best!
The cleaning device includes a support frame installed on a floor of a workshop, a roller rotation unit that is installed on an upper surface of the support frame and rotates the hemming roller that has entered the upper surface of the support frame through the hemming robot, and a scraper that is installed to be movable back and forth on the support frame while facing the roller rotation unit and removing foreign substances on the surface of the hemming roller.
US Patent 11260428
THE BOEING COMPANY
Tools and Methods for Creating a plurality of aligned holes from a plurality of near full-sized holes with less than perfect alignment.
What is this invention?
Tools and methods for forming aligned holes from near full-sized holes
There once was a tool for creating aligned holes
The cutting member had a first diameter
The pilot member was connected and coaxial
With a centering member positioned between
So that the second diameter could correspond to the positional tolerance of misalignment of near-full sized holes
There are a lot of different ways to create holes in materials - but none quite like the Boeing Company's Tools and Methods for Forming Aligned Holes. This innovative tool allows you to easily form aligned holes from near-full sized holes, which can be incredibly helpful in a variety of applications.For example, say you need to make some small adjustments to a piece of equipment. Instead of taking the time to remove and replace all the screws yourself, you can use Tools and Methods for Forming Aligned Holes to quickly make the necessary changes. And because this tool is precision-made, you can be sure that your adjustments will be precise - no matter how large or small they may be.Plus, since this system is designed for use with near full sized holes, it's perfect for a wide range of applications. Whether you're repairing something damaged or creating new parts for an existing machine, Tools and Methods for Forming Aligned Holes will help get the job done quickly and efficiently.
This document describes a tool and method for creating aligned holes from a plurality of near full-sized holes. The cutting member has a first diameter and the pilot member is connected to and coaxial with the cutting member. A first section of the pilot member includes a centering member that is positioned between the cutting member and the second section having a second diameter. The centering member may include a cutting surface. The second diameter corresponds to a positional tolerance of misalignment of a plurality of near full-sized holes of the same diameter and a full-size hole diameter. The centering member may have a third diameter between the first and second diameters. The centering member may be tapered. The pilot member may be inserted into a plurality of near-full sized holes and the cuttingmember may cut through the holes to form aligned full sized holes
US Patent 11260459
HONDA MOTOR CO., LTD.
The Flexible Ring Fitting Device Allows You To Fit Rings Anywhere!
What is this invention?
Flexible ring fitting device
There once was a flexible ring device,
That could dispose a ring relative to a workpiece.
With assembly mechanisms 421 and 422,
It had an arm portion 424 that rotated and pushed,
So the elastic body 51 could press with respect to the workpiece.
Do you ever find yourself struggling to fit a flexible ring around a workpiece? The Flexible Ring Fitting Device from Honda Motor Co., Ltd. may be just the solution you're looking for! This ingenious device includes a flexible ring disposition mechanism 10 that allows you to easily dispose of the flexible ring R relative to an annular groove G on the workpiece W. Plus, the elastic body 51 urges the arm portion 424 of the flexible ring assembly mechanisms 421 and 422 so as to press the arm portion 424 against the workpiece W with great force - making it easy to get that perfect fit every time. Whether you're working on a small project or trying to tackle a more complex one, this tool will help make things go much smoother.
The flexible ring fitting device includes a flexible ring disposition mechanism 10 for disposing a flexible ring R relative to an annular groove G of a workpiece W and flexible ring assembly mechanisms 421 and 422 including an arm portion 424 rotating while pushing the flexible ring R along the outer periphery of the workpiece W. The elastic body 51 urges the arm portion 424 of the flexible ring assembly mechanisms 421 and 422 so as to press the arm portion 424 with respect to the workpiece W.
US Patent 11260482
Canon Kabushiki Kaisha
An Easy-Sucking Apparatus for Picking Up Objects in Packaging Material
What is this invention?
Information processing apparatus and information processing method
There was an apparatus for processing information
That determined the area to be suctioned by a device
Based on the state of the surface of the packaging material
regarding ease of suction in each area,
So that the packaged object could be picked up without fail.
Canon Kabushiki Kaisha has invented a new information processing apparatus that can be used to determine an area of a packaged object in a packaging material to be suctioned by a suction device for picking up the packaged object. This system uses input from an image capture unit to identify areas on the surface of the packaging material where suction is easy or difficult, and then uses this information to determine which area should be picked up by the suction device. This innovative technology makes it easier than ever before to pick up objects that are stuck in packaging material - making it possible to remove items like toys, books, and other small objects from their packaging without any damage.
The information processing apparatus determines an area of a packaged object to be suctioned by a suction device for picking up the packaged object. The determining unit based on a state of the surface of the packaging material regarding ease of suction in each area determined, determines the area to be suctioned.
US Patent 11260534
CANON KABUSHIKI KAISHA
An Imprint Apparatus That Allows for Precise Patterning with a Mold
What is this invention?
Imprint apparatus, planarized layer forming apparatus, forming apparatus, control method, and method of manufacturing article
There once was an imprint apparatus
That included a supplier and controller
The supplier could supply the material
On the substrate in accordance with a pattern
And the controller would control the supplier
To obtain contact timing at each position
Then determine the supply pattern based on what was obtained
In today's world, it is more important than ever to have precision when it comes to manufacturing. That is why we are excited to introduce the Canon Imprint Apparatus - a system that allows for precise imprinting of patterns onto substrates. This innovative apparatus features a supplier that supplies the imprint material in accordance with a supply pattern determined by the controller, meaning that you can be sure that your products will always look professional and consistent. Thanks to its intuitive controls and contact timing detection capabilities, this apparatus makes bringing your mold and imprint material into contact quick and easy - perfect for high-volume production environments.
An imprint apparatus is provided that includes a supplier and controller. The supplier is configured to supply the imprint material on the substrate in accordance with a supply pattern of the imprint material. The controller is configured to control the supplier, and obtain a contact timing as a timing at which the mold and the imprint material are brought into contact with each other at each of a plurality of positions of the mold. The controller then determines the supply pattern based on the obtained contact timing.
US Patent 11260577
The Boeing Company
STRUCTURAL FRAME MADE OF FIBER REINFORCEMENT AND RESIN
What is this invention?
Automated resin and fiber deposition for resin infusion
There once was a process for making
Composite structures, which were quite amazing.
You lay down strips of resin film
And the fiber reinforcement would be infused with them.
This created a strong and sturdy bond,
Which was perfect for applications beyond.
The Boeing Company has invented a new way to fabricate composite structures - by layering fiber reinforcement and resin film together on a tool. This process is incredibly efficient, and it allows for the fabrication of complex structures without having to use many different pieces of equipment. Not only does this method save time and money, but it also produces high-quality materials that are resistant to wear and tear. If you're looking for a new way to create durable products, look no further than the Boeing Company!
The patent describes the process of creating a composite structure, which is made up of at least one ply of fiber reinforcement and at least one layer of resin. The resin film layer is formed by laying strips of resin film over the fiber reinforcement, and the fiber reinforcement is infused with resin from the resin layer.
US Patent 11260606
Canon Kabushiki Kaisha
Eject liquid with ease with this handy device
What is this invention?
Liquid ejection head, liquid ejection apparatus, and liquid ejection module
This liquid ejection head is great,
It has a pressure chamber for first and second liquid to flow inside.
A pressure generation element applies pressure to the first liquid,
And an ejection port ejects the second liquid with great precision.
Canon Kabushiki Kaisha has just released a new liquid ejection head that is sure to revolutionize the way you do your welding. This head includes a pressure chamber that allows two liquids - usually water and oil - to flow inside it, a pressure generation element that applies pressure to the liquids, and an ejection port that sends the liquids flying outwards. In situations where the first liquid flows in one direction and the second liquid flows in another, they cross paths near the ejection port - at which point the second liquid is ejected out of the machine thanks to its higherpressure surroundings. This technology could make your job much easier, as it eliminates the need for multiple ports and tubes on your welder. So if you're looking for a new way to improve your welding process, be sure to check out Canon's latest invention!
This liquid ejection head includes a pressure chamber that allows a first liquid and a second liquid to flow inside. A pressure generation element applies pressure to the first liquid, and an ejection port ejects the second liquid.
US Patent 11260658
CANON KABUSHIKI KAISHA
Printing Apparatus Keeps Printing Print Media Secure
What is this invention?
Printing apparatus and printing method
There was a printing apparatus great
That had a print unit and holding plate.
It could detect the medium
And then would move in due time,
So that it could get information of the state.
With so many different types of print media available, it can be difficult to know which one to use when printing your documents. Wouldn't it be great if you could just tell the printer what type of print medium you have waiting in the holding unit, and leave everything else up to the machine? That's exactly what Canon's new printing apparatus and method offers - a way to simplify the process of printing by automatically taking into account the type of print medium that is currently being held by the holding unit. This means that no matter what kind of document you are trying to print, Canon's apparatus will be able to handle it with ease.
A printing apparatus including a print unit and a holding unit is capable of holding multiple types of print medium. The detecting unit is able to detect the print medium and the holding unit. The movement unit is capable of relatively moving the detecting unit and the holding unit in a first direction and in a second direction intersecting the first direction. In addition, the control unit controls the detecting unit and the movement unit in a case where one type of print medium is held by the holding Unit, to obtain position information of that type of print medium before printing occurs on it, and in a case where another type different from that type of print medium is held by the holding Unit, not to obtain position information for that other type of print media.
US Patent 11260673
Hyundai Motor Company
Hybrid Starter and Generator (HSG) Cooling Control Apparatus for a Hybrid Vehicle - HSG Cooling Control Method
What is this invention?
HSG cooling control apparatus for hybrid vehicle, HSG cooling control method thereof, and hybrid vehicle including HSG cooling control apparatus
The hybrid starter and generator
Has a cooling control apparatus
That keeps it from overheating
In the idle charging mode.
If the temperature does rise,
Then the cooling unit is turned on.
Hyundai Motor Company has invented a new HSG cooling control apparatus that can help keep your hybrid vehicle running smoothly and efficiently. This apparatus includes a receiver that receives driving information of the engine and the hybrid starter and generator (HSG), a cooling unit that cools the HSG, and a controller that determines whether the HSG is in an idle charging mode based on this information. If the HSG is in this mode, the controller then determines whether the temperature of the HSG is greater than a first cooling-required temperature. If so, the controller then controls the cooling unit to be turned on. This system will help to keep your hybrid vehicle running at its best by ensuring that the HSG remains cooled even when it's not being used - making it more efficient overall.
The hybrid starter and generator (HSG) cooling control apparatus for a hybrid vehicle includes a receiver configured to receive driving information of an engine and the hybrid starter and generator (HSG), a cooling unit configured to cool the HSG, and a controller configured to control the cooling unit. The controller determines whether the HSG is in an idle charging mode based on driving information of the engine and the HSG, determines whether the temperature of the HSG is greater than a first cooling-required temperature when the HSG is in the idle charging mode, and controls the cooling unit to be turned on when the temperature of the HSG is greater than the first cooling-required temperature.
US Patent 11260738
Ford Global Technologies, LLC
Assembly Keeps You Moving
What is this invention?
Vehicle frame assembly
There once was an assembly of parts
That included a vehicle frame with a crossmember.
The drive unit was supported in the passage it made,
And a stabilizer was fixed to the side.
This restricted movement in one direction, but not the other--
Allowing for some give and take!
Vehicle frame assemblies have always been a key component in the design of vehicles. They provide structural support and allow for movement of various components within the vehicle, making them ideal for a variety of applications. Recently, Ford Global Technologies, LLC has introduced an innovative vehicle frame assembly - one that features a stabilizer that allows for only limited movement of the drive unit within the passage. This helps to reduce noise and vibration levels while also ensuring that the drive unit remains stable during operation.
An assembly includes a vehicle frame having a crossmember defining a passage. The assembly includes a drive unit supported by the crossmember in the passage. The assembly includes a stabilizer fixed to the drive unit, the stabilizer permitting movement of the drive unit in a first direction relative to the passage and restricting movement of the drive unit in a second direction opposite the first direction.
US Patent 11260748
FORD GLOBAL TECHNOLOGIES, LLC
Auxiliary Battery Charging Controlled by Low Cost Charging Windows
What is this invention?
Auxiliary battery charging systems and methods for electrified vehicles
There once was a car with an aux battery
That needed to be charged up just right
So it wouldn't be too costly
The method was simple and straightforward:
Only charge during low-cost windows, overnight.
Electric vehicles are becoming more and more popular, but one of the big challenges facing them is finding a way to charge their auxiliary batteries. Nowadays, most electric cars come with some form of charging infrastructure - but this doesn't always mean that there's enough juice available when you need it. That's where auxiliary battery charging systems comes in handy - they can help to keep your car's battery charged even when there isn't any electricity around.
The patent describes vehicle systems and methods for controlling charging of an auxiliary battery of an electrified vehicle. Exemplary charging methods align the charge management of an auxiliary battery to occur only during low cost charging windows. This allows the auxiliary battery to be charged more cheaply, while still ensuring that it is fully charged when required. By managing the charge of the auxiliary battery in this way, it is possible to extend the life of the battery by limiting its use during high-cost charging windows.
US Patent 11260762
HONDA MOTOR CO., LTD.
Lawn Mower Comes with a Charging Station!
What is this invention?
Autonomous travel work machine and charging station
There once was a lawn mower named Fred
Who had a pair of power receiving terminals
One in the cover, one in the body
So he could charge up when he got low on juice
He was always prepared to cut grass with no fuss!
Honda has come up with a new way to charge your lawn mower - by using a charging station! This innovative machine has at least one first structure in which a pair of power receiving terminals are separately disposed in the vehicle body cover and the vehicle body that are different parts from among a plurality of parts constituting the lawn mower, or a second structure in which the power receiving terminal, which is one of the pair of power receiving terminals, has a downward-facing contact surface that comes into contact with the charging station. This means that you no longer have to find an open outlet to plug your lawnmower in - you can simply park it next to the charging station and get started on your next cut. Not only does this system make Charging easier than ever before, but it also keeps your working area small and light - perfect for on-the-go projects.
The lawn mower has at least a first structure in which a pair of power receiving terminals are separately disposed in the vehicle body cover and the vehicle body that are different parts from among a plurality of parts constituting the lawn mower, or a second structure in which the power receiving terminal, which is one of the pair of power receiving terminals, has a downward-facing contact surface that comes into contact with the charging station.
US Patent 11260765
Hyundai Motor Company
Low Voltage DC-DC Converter Keeps Your Vehicle Running
What is this invention?
System and method for controlling low voltage DC-DC converter for vehicle
There once was a system so great
It could control the output of a low voltage DC-DC converter
When the auxiliary battery was charged to a preset reference value or more
The controller turned off the first relay and outputted a minimum voltage capable of operating the electric device
Vehicles have become increasingly popular over the years, and one of the main reasons for this is the ability to power them with electricity from a variety of sources. One of these sources is a low voltage DC-DC converter, which helps to convert the high voltages generated by engines into lower voltages that can be used to power various parts of a vehicle.The Hyundai Motor Company has come up with a new system for controlling low voltage DC-DC converters in vehicles - perfect for those times when you need to use your vehicle's battery but don't want to drain it completely. This system includes a low voltage DC-DC converter and an electric device connected thereto, as well as a first relay and auxiliary battery connected in series. When the main battery is being charged, the first relay is turned off so that minimal voltage is outputted by the converter - enough to keep the electric device functional. However, when the auxiliary battery reaches a preset reference value (usually around 10% full), the controller turns on the first relay and allows full voltage output from the converter so that your vehicle can run properly while charging its own battery.
The system described in this patent allows for the controlled output of a low voltage DC-DC converter to an electric device. When the auxiliary battery is charged to a preset reference value or more, the controller turns off the first relay and outputs a minimum voltage capable of operating the electric device.
US Patent 11260766
HYUNDAI MOTOR COMPANY
AC Power for Your Vehicle - Now with a Moveable Inverter!
What is this invention?
Movable power generating system and method for vehicle
There once was a vehicle so nifty
Its movable power generating system was quite shifty
Inverter, motor, and switch block were included
So that when the battery power was depleted
The external power supply unit could be used
Looking for a way to power your vehicles' accessories and systems without having to rely on traditional batteries? Look no further than Hyundai Motor Company's new movable power generating system! This system allows you to generate AC power from your battery, which can then be used to power just about anything in your vehicle. Not only is this a great option for powering your accessories, but it also eliminates the need for bulky and heavy batteries - making it easier and more convenient to take your vehicle wherever you go.
The movable power generating system for a vehicle may include an inverter, a motor, and a switch block. The inverter may receive power from the battery in the vehicle to generate AC power. The motor may receive the AC power from the inverter and may be operable to produce rotational motion. The switch block connected to the output terminal of the inverter and for branching the AC power. And, an external power supply unit is connected to the switch block and is operable to output the AC power.
US Patent 11260770
Honda Motor Co., Ltd.
Vehicle Power Supply System Prevents Overcharging
What is this invention?
Vehicle power supply system
There was a power supply system for a car
That had two batteries, one near and one far
The first was for use
The second for juice
And the voltage converter kept them both charged up to par
Vehicle power supply systems are essential for powering our vehicles in the event of a breakdown. With so many different makes and models of cars on the road, it can be difficult to find a system that will work with your specific vehicle. That's where Honda comes in - they've developed a versatile system that works with nearly any car on the market.The Honda Vehicle Power Supply System includes a pair of inverters - one connected to each battery - and a voltage converter. This setup allows you to charge either battery while the other is being used to power your car. In addition, if your car's battery runs low, the control device will divert some of the power from the second battery back into the first to help keep things running smoothly. Overall, this system is incredibly simple and easy to use, making it ideal for anyone who needs reliable vehicle power during emergencies or breakdowns.
The vehicle power supply system includes a first power line connected by a first inverter and a first battery, a second power line connected by a second inverter and a second battery, a voltage converter, and a charging and discharging control device operating the inverters and the voltage converter. The control device charges the second battery with regenerative electric power that is supplied from the second inverter to the second power line in cases where one of two SOCs (second regeneration permission upper limit) is equal to or less than the lower limit. In addition, when the SOC is larger than the lower limit, but not larger than an upper limit that corresponds to full charge of the first battery, then at least some of regenerative electric power supplied from the second inverter is transferred to recharge or discharge the first battery through voltage converter and first power line.
US Patent 11260771
Ford Global Technologies, LLC
Vehicle Seating Assembly Provides Secure Standing Position
What is this invention?
Manual and powered actuation of seating assembly
A vehicle seating assembly has a seat,
Which can move up to take a standing position.
This is all thanks to the gear assembly,
Which includes a pinion that can rotate.
The frame is locked in place by a disk,
But when it's disengaged, the frame can rotate.
Vehicle seating is a vital part of any car, and it's important that the assembly is able to move between sitting and standing positions smoothly and easily. The Manual Seat Actuation system from Ford Global Technologies, LLC meets this need by including a seat frame that can be moved between these two positions using just a few gears. This system is easy to use - simply rotate the locking disk assembly into the disengaged position, and you're good to go!
A vehicle seating assembly includes a seat frame movable between a sitting position and a standing position, coupled to a pivot bracket, a cross member extending through the pivot bracket and defining an axis of rotation, and a gear assembly coupled to the pivot bracket. The gear assembly includes a sector bracket rotationally coupled to the cross member, and a pinion gear operable to rotate along the sector bracket from a first position to a second position, thereby moving the seat frame between a sitting position and standing position. The vehicle seating assembly further includes locking disk assembly coupled to the pivot bracket such that if the locking disk assembly is in an disengaged position relative to sector bracket then the frame is rotatable about axis of rotation defined by cross member.
US Patent 11260776
HONDA MOTOR CO., LTD.
Moveable Footrest Makes Getting In And Out Of Your Vehicle A Breeze
What is this invention?
Active vehicle footrest
There once was a car with a moveable footrest,
So you could always have a comfortable place to rest.
The mechanism that controlled the movement,
However, was known to be quite faulty.
On many occasions it would get stuck,
Leaving passengers feeling rather stuck!
There's nothing quite like a good footrest to take the strain off your feet during long car rides. But what if you didn't have to leave your feet behind when hopping into a new vehicle? That's where the Honda Foot Rest comes in - an invention that allows passengers to rest their feet on a movable footrest while riding in cars.The Foot Rest is designed for use with vehicles of all shapes and sizes, and it can be moved from its ingress/egress position (where it sits below the seating surface) to its transport position (closer to the seating surface) with just a few simple movements. This means that even small cars can accommodate this handy device, making long trips much more comfortable for everyone involved. Plus, since it's portable, you can take it with you wherever you go - perfect for weekend getaways or extended road trips!
The passenger carrying portion of this vehicle includes a moveable footrest that can be moved from an ingress/egress position to a transport position that is closer to the seating surface. This movement mechanism controls the movement between these positions, so you can always have a comfortable place to rest your feet.
US Patent 11260784
Hyundai Motor Company
Controlling Electric Vehicle Tone with Linearity Estimation
What is this invention?
Method of controlling tone of electric vehicle based on motor vibration in deceleration or regenerative braking conditions
There once was a method for EVs
That used order components from the motor's vibrations
To calculate an output torque with great precision
And set an EV mode tone in deceleration condition
This new Hyundai Motor Company invention is a step in the right direction for electric vehicles - it allows you to control the tone of your car based on motor vibration. By calculating order components from vibration signals, you can determine which frequency has the most linearity with respect to output torque, and then use that frequency to control the sound level of your EV. This technology is especially useful in deceleration or regenerative braking conditions, where you want to keep your passengers calm without having to change the music or sound settings.
The method of controlling a tone of an electric vehicle (EV) includes calculating order components from vibration signals of a rotating motor, extracting an Nth order component having a determination coefficient R2 which represents linearity with respect to an output torque of the motor and is greater than or equal to a predetermined value, converting an RPM of the motor into a frequency and calculating an order frequency, arranging the order components by applying a vibration level of the Nth order component to a level of the order frequency to be output and setting an EV mode tone. In deceleration, the method determines a deceleration condition and applies the vibration level of the Nth order component to level control of the order frequency.
US Patent 11260792
FORD GLOBAL TECHNOLOGIES, LLC
Retractable Step for Pickup Truck Tailgate Provides Support for Workpiece
What is this invention?
Detachable workpiece support apparatus for a tailgate step
There once was a workpiece support
That was designed for use with a tailgate
It had two members and a bar
Which could be fixed or detached, depending on the user's needs
This versatile tool helped many workers complete their tasks!
With so many people working on projects in their pickup trucks, it's important to have a dependable way to support a workpiece while you're welding. Ford Global Technologies has come up with the perfect solution - detachable workpiece supports that attach easily and securely to your truck's tailgate step. No more struggling to hold onto a shaky piece of metal while you weld!
The workpiece support is designed for use with a pickup truck tailgate. The step includes two support members, a workpiece support bar and riser that are attached to the support members and to each other at a right angle. The attachments can be fixed or detachable, depending on the user's needs.
US Patent 11260796
Ford Global Technologies, LLC
The Seat that Moves Between Upright and Reclined Positions is Safe and Convenient
What is this invention?
Side airbag with adaptive positioning for reclining seat
There once was an assembly with a seat,
Which could move 'tween an upright and reclined position.
A track was coupled to its side,
And a rail to which it was operably aligned.
An airbag inflator module was mounted on the rail--
So when the seat changed position, the module would slide along without fail!
With so many people traveling for work these days, it is important to have a seat that can move between an upright position and a reclined position - something that the Side airbag with adaptive positioning for reclining seat from Ford Global Technologies, LLC can provide. This innovative assembly features a track that is coupled to a side of the seat, as well as a rail operably coupled to the rail. This allows the airbag inflator module to slide along the rail when the seat moves between these positions, ensuring that your safety is always priority one when you are on-the-go.
The present disclosure relates to an assembly that has a seat, which can move between an upright position and a reclined position. The assembly also includes a track that is coupled to a side of the seat and a rail operably coupled to the rail. The assembly further includes an airbag inflator module that is mounted on the rail, such that the airbag inflator module slides along the rail when the seat moves between the upright position and the reclined position.
US Patent 11260820
Honda Motor Co., Ltd.
Prediction Device Predicts Traffic Jam Ahead
What is this invention?
Prediction device, prediction method, and storage medium
There once was a device quite nifty,
That could tell when a traffic jam would be shifty.
Based on changes in the land,
It would make a prediction,
So you could avoid being stranded!
Traffic jams are a common occurrence on our roads, and they can be quite frustrating for drivers. Luckily, there is now a way to predict when one will occur - thanks to Honda's new prediction device. This device uses a camera to repeatedly image the region ahead of a vehicle, and then extracts regions that include other vehicles. Based on this information, the predictor is able to predict when a traffic jam will occur in the road on which the vehicle is traveling. If you're ever caught in one of these jams, be sure to take advantage of this amazing technology!
A prediction device can predict that a traffic jam will occur in a road on which there is the vehicle based on a change in the region extracted from each of the plurality of images by the extractor between the images.
US Patent 11260858
HONDA MOTOR CO., LTD.
Vehicle Control System Keeps Lane Maintained with Second Steering Controller
What is this invention?
Vehicle control system, vehicle control method, and storage medium
There once was a vehicle control system
That included a first steering controller
It executed first steering control
To keep the traveling lane in hold
But if a command value did deviate left or right
Then the second steering controller would take over and reflect the command value with all its might
Vehicle control systems have come a long way in the past few years, and one of the most important advancements has been in steering control. With today's systems, you can keep your traveling lane intact even when using first steering control - a key feature for keeping your vehicle on track while driving.
The vehicle control system includes a first steering controller that executes first steering control for controlling a steering device such that a traveling lane is maintained. If a command value given to the steering device in the first steering control has continued to deviate either left or right, then the second steering controller executes the second steering control by reflecting the command value given in the first steering control.
US Patent 11260859
Honda Motor Co., Ltd.
Vehicle Control Device Gives Lane Change Assistance and Automated Lane Change Control
What is this invention?
Vehicle control device
There once was a driver so nifty
Who used an ALC switch to stay thrifty
When it came time to change lanes
The automated system took the reins
While assistance-based control gave tips along the way
Vehicle control devices have come a long way in recent years, and one of the most important developments has been the introduction of automated lane change control. This technology allows drivers to automatically move from their current travel lane to another when they need to change lanes - making it much easier and faster than ever before.The Honda ALC switch is one of the latest devices to incorporate this technology, and it provides drivers with instructions on how to perform lane change assistance control or automated lane change control. With this switch installed in your car, you can easily take care of all your lane changing needs without ever having to touch the wheel!
The vehicle control device includes a control instruction unit (ALC switch) that allows the driver to choose between automated lane change control and assistance-based lane change control. The ALC switch will give an instruction to one of these modes, depending on what is needed at the time. Automated lane change control will take care of the necessary travel controls while assistance-based lane change control will provide guidance and notification to the driver about when it's time for them to make a lane change.
US Patent 11260865
HONDA MOTOR CO., LTD.
Vehicle Control Device Accelerates Vehicle To Overtake Another Vehicle
What is this invention?
Vehicle control device, vehicle control method, and storage medium
There was a vehicle control device
That could cause some serious strife
If you tried to overtake
While another car was in your wake
You might just end up with a new lease on life!
Vehicle control has come a long way in the past few decades, and one of the most important advancements has been in vehicle control devices. Today we are introducing the Honda Motor Company Vehicle Control Device - a device that can be used to help you overtake another vehicle on the road without having to risk getting into an accident. With its ability to accelerate and decelerate your car at just the right moments, this device makes overtaking much easier than ever before.
The vehicle control device includes an action controller that is configured to control an action of the vehicle, in which, in a case where there is another vehicle traveling on a second road adjacent to a first road on which the vehicle is traveling, and the vehicle is controlled to overtake another vehicle, the action controller is configured to accelerate the vehicle, causes the vehicle to show an intention to enter the second road when the vehicle is located a predetermined distance or more in front of another vehicle in an advancing direction of the vehicle after the Vehicle is accelerated, and decelerates the Vehicle while maintaining it's location in front of another vehcile at a timing according to entry intention.
US Patent 11260866
FORD GLOBAL TECHNOLOGIES, LLC
Computer detects potential hydroplaning area and responds accordingly!
What is this invention?
Hydroplaning prevention
There once was a computer system
That used data from vehicle sensors
To identify potential hydroplaning areas
On roads that were getting wetter.
If the area was deemed to be in danger,
The computer would activate components
To help prevent a crash from occurring.
Hydroplaning is a dangerous condition that can occur when a car's tires slip on the wet surface of a road. Ford Global Technologies, LLC has developed a computer system that can help prevent this situation by detecting potential hydroplaning areas and activating components of vehicles accordingly. By using topographic data and vehicle sensor data, this system is able to identify potential hydroplaning areas before it happens - ensuring that you and your passengers stay safe.
The patent describes a computer system that uses data from vehicle sensors and topographic maps to identify potential hydroplaning areas on roads. If the area is deemed to be in danger of becoming wet, the computer will activate certain components of the vehicle to help prevent a crash.
US Patent 11260867
THE BOEING COMPANY
Apparatus, systems, and methods that include variable length tie rods - linkages with non-circular cross-sections
What is this invention?
Variable linkage for tie-rods
There once was a tie rod linkage
With first, second, and third apertures
The first distance 'twixt them
Was quite different from the second
So fourth aperture had to be inserted!
With so many tie rods out there that are just a bit too short or too long, it can be frustrating trying to find the right length for your project. That's where Variable Linkage for Tie Rods comes in - a new invention from The Boeing Company that makes it easy to connect together tie rods of the correct length without having to measure each one individually. This ingenious system includes four apertures - two on the base of the linkage and two in the first and second fingers - that allow you to adjust the distance between each rod without ever having to remove them from your project. So whether you're connecting together dozens of short pieces or just a few long ones, VLTR will make sure everything is just right.
The apparatus, systems, and methods described herein include a variable length linkage for connecting together tie rods. The linkage includes first, second, and third apertures. There is a first distance between the first aperture and the second aperture and a second distance between the first aperture and the third aperture. The apparatus may also include a fourth aperture having a third distance between the first aperture and the fourth aperture. The second, third, and fourth apertures may each have a non-circular cross-section. The linkage may include a base, a first finger, a second finger, and a third finger that each extend from the base. US Patent 11260903
The Boeing Company
New Hypersonic Transport Vehicle Exterior Panel Made of Superplastic Materials
What is this invention?
Reinforced superplastic formed and diffusion bonded structures
There once was a hypersonic transport
That needed an exterior panel made of sorts
So they used superplastic materials
And titanium skins for the structure
To make it both strong and flexible in design
With the increasing demand for hypersonic transport vehicles, it is important that these vehicles are able to withstand high thermal stresses. One way to achieve this is by using an exterior panel made of superplastic materials that are resistant to high temperatures. The Boeing Company has developed a method for forming and diffusion bonding an exterior panel like this, and the results are impressive. Not only does this panel resist heat damage, but it also provides structural support to the underlying skeletal structure - making it a perfect solution for hypersonic transport vehicles. Thanks Boeing!
The patent describes an exterior panel for a hypersonic transport vehicle that is made of superplastic materials. The exterior panel includes a titanium skin that is fixed to an underlying reinforcement layer made of a TZM alloy, which helps to support the skin when it is heated to high temperatures. A separate interior skin is attached to the frame member, and a multicellular core sandwiched between the skins imparts tensile and compressive strength to the exterior panel. This method of manufacturing the panel allows for greater flexibility in design and increases the overall durability of the hypersonic transport vehicle.
US Patent 11260952
THE BOEING COMPANY
Generating and Dispersing Sun-Reflective Aerosols
What is this invention?
Aircraft aerosol dispensing method, apparatus, and system
There once was an aircraft engine
That ran on a fuel with an additive
The exhaust would then create
A plume of reflective consumosl
Which would help reflect the sun's light
The Boeing Company has invented a new way to generate and disperse plumes of reflective aerosols - an important step forward in aircraft design. By supplying fuel to an engine and adding an additive, we are able to create a powerful source of light that can be used for various purposes on-board aircraft. Not only does this system improve the performance and efficiency of aircraft engines, but it also helps keep passengers safe by providing increased visibility during nighttime flights. We hope that this innovative technology will help make aviation even more efficient and affordable in the years to come.
The patent provides a method, system and apparatus for generating and dispersing plumes of reflective aerosols. Methods include supplying fuel to an engine of an aircraft for combustion; supplying an additive to the fuel, where the additive includes at least one of a reflective aerosol or a precursor thereof; combusting the fuel and the additive to the fuel in the engine; and generating, in the exhaust from the engine, a plume of reflective aerosol, where the reflective aerosol reflects sunlight.
US Patent 11260974
The Boeing Company
New Filtration Apparatus Keeps Your Home Clean
What is this invention?
Filtration apparatus for use with aircraft
There once was a filtration apparatus
That included a housing and cavity
With a filter located inside
And a cleanout system to provide
A way to remove particulates without taking out the filter!
We all know that keeping our aircraft clean is important - not only for the safety of passengers, but also for the health of the plane itself. With today's announcement from The Boeing Company, we can now add another essential piece of equipment to the arsenal: filtration apparatus!This new system allows you to remove particulate from your filter without having to remove it from the housing - meaning less downtime and more efficient operation. Plus, thanks to its accessible cleanout inlet and outlet, this apparatus is perfect for quick and easy maintenance. So if you're looking for a reliable way to keep your aircraft clean and healthy, look no further than filtration apparatus!
The filtration apparatus includes a housing including a plurality of walls defining a cavity, a filter located in the cavity, and a cleanout system coupled to the housing. The cleanout system includes a cleanout passageway between an outer surface of the housing and the filter. The cleanout system also includes a cleanout inlet accessible from the outer surface of the housing and a cleanout outlet in fluid communication with the filter. The cleanout outlet enables removal of particulate from the filter without removing the filter from the housing.
US Patent 11260977
THE BOEING COMPANY
A Multi-Layer Shell Structure for a Vehicle and Method of Providing the Same
What is this invention?
Spacecraft high tensile fabric barrier for hot re-entry gases
There once was a multi-layer shell
That protected a vehicle quite well
With a TPS layer
And a high tensile fabric barrier
No gas could enter, even if there was a hole!
Vehicles are becoming increasingly safer and more secure, but one downside is that they can't handle the extreme heat and pressure of re-entry very well. That's where spacecraft high tensile fabric barrier (HTFB) technology comes in - it's a layer of protection that helps keep the cabin safe during re-entry.The HTFB is made up of a thermal protection system (TPS) layer, a structural layer connected to the TPS layer, and a high tensile fabric barrier layer bonded to the structural layer. This combination creates a seal on the inside of the vehicle that prevents gas from entering through any holes in the structure - even if something goes wrong during re-entry. Not only does this provide peace of mind for passengers, it also makes repairs much easier in the event of an accident.We're excited to see what new applications HTFBs will be used for in the future!
A multi-layer shell structure for a vehicle is described. The multi-layer shell structure includes a thermal protection system (TPS) layer, a structural layer connected to the TPS layer, and a high tensile fabric barrier layer bonded to the structural layer. Room-temperature-vulcanizing silicone may be used to bond the TPS layer to the structural layer and bond the high tensile fabric barrier layer to the structural layer. The high tensile fabric barrier layer may create a seal on the structural layer. The multi-layer shell structure may include inner shell enclosing a passenger and/or cargo compartment and an annulus between the inner shell and the high tensile fabric barrier layer. The high tensile fabric barrier layer may prohibit entry of gas into the annulus in the event a hole is created through a portion of the multi-layer shell structure.
US Patent 11260995
CANON KABUSHIKI KAISHA
Keep your documents safe with our moving cover apparatus
What is this invention?
Sheet conveyance apparatus and image forming apparatus
There was a conveyance apparatus,
With a first and second unit.
The second unit had a cover,
And was movable between two positions.
The retaining portion kept the cover open,
Allowing the sheet to be conveyed to the path.
Canon has released a new sheet conveyance apparatus that is sure to make your job as a printer or photo editor a lot easier. The new apparatus includes a first conveyance unit and a second conveyance unit - both of which can be moved between two positions, allowing you to easily and quickly move sheets between different parts of the machine. Additionally, the retaining portion on the second conveyance unit ensures that the cover stays in place when it's in use, preventing any potential damage or messes.
A sheet conveyance apparatus includes a first conveyance unit, a second conveyance unit including a cover and configured to be movable between a first position where a sheet conveyed from the first conveyance unit can be conveyed to a sheet conveyance path and a second position separated from the first position, and a retaining portion configured to retain the cover at an open position and to retain the second conveyance unit at the second position through the cover retained at the open position. In this case, if the cover is positioned at the open position in which the second conveyance unit is positioned at the second position, then the retaining portion retains both units in that state.
US Patent 11261051
