Most innovative companies for 10/25/2022 (new inventions)
Exciting new inventions from Ford Global Technologies, Llc, Hyundai Motor Company, Canon Kabushiki Kaisha, GM Global Technology Operations Llc And Hyundai Mobis Co., Ltd.
This is a weekly article summarizing a handful of inventions from the most innovative companies in the world. The summaries are created by an A.I. and proof-read by a human before publication. Attempts are made to ensure accuracy of the descriptions, but it is very much a work in progress. Each invention description is preceeded by a poem about the invention that is written by the A.I. I have found the limerick is actually quite good at explaining the invention in simple terms. Enjoy!
FORD GLOBAL TECHNOLOGIES, LLC
New Sensor Assembly Keeps Your Car Fresh
What is this invention?
Sensor assembly with cleaning
There once was a sensor assembly
That included a housing and chamber
First and second sensors were placed
And a blower outlet was positioned to face
The windows that outwardly faced.
Looking for a way to keep your sensors clean and free of dust and debris? Look no further than the FORD GLOBAL TECHNOLOGIES, LLC sensor assembly! This handy device includes a housing with a chamber that is perfect for holding your sensors. The chamber has a first outlet that allows you to direct air across the windows on your sensors, while the second outlet directs air directly into the blower inlet. This ensures that your sensors are always kept clean and free of any obstructions. Whether you're driving through dusty conditions or just need to clear out any built-up dust, this assembly is perfect for you!
The sensor assembly includes a housing including a chamber, first and second sensors disposed in the chamber, and a blower outlet in the chamber. The first and second sensors include windows that face outward from the chamber. The blower outlet is positioned to direct air across the windows of the first and second sensors. The flexible hose extends from a first end positioned to receive ambient air to a second end positioned to direct air into the blower inlet.
US Patent 11478827
Hyundai Motor Company
Vehicle Body Assembly System Defines Pre-Buck and Main-Buck Sections Along Conveyor Route
What is this invention?
Vehicle body assembly system
A vehicle body assembly system is defined,
With a preset pre-buck section along the way.
It includes pre-buck units at both sides,
Restricting lower portions of side assemblies.
The main-buck units then do their job,
Restricting upper portions with second welding robot.
The vehicle body assembly system from Hyundai Motor Company is the latest innovation in automotive manufacturing. This system defines a preset pre-buck section and main-buck section along a conveying route of a floor assembly, allowing for more efficient production of vehicles. The pre-buck units are installed at both sides of the conveying route and restrict lower portions of side assemblies with respect to both sides of the floor assembly. The main-buck units are installed at both sides of the conveying route and restrict upper portions of the side assemblies. Finally, the system posts assemble vehicle body components to the upper portions of the side assemblies by second welding robot. This system is more efficient than previous systems and allows for a higher quality product.
A vehicle body assembly system defines a preset pre-buck section and a preset main-buck section along a conveying route of a floor assembly. The system includes pre-buck units which are installed at both sides of the conveying route in the pre-buck section, respectively, restrict lower portions of side assemblies, which vary in accordance with a type of vehicle, with respect to both sides of the floor assembly. The system also includes main-buck units which are installed at both sides of the conveying route in the main-buck section, respectively, restrict upper portions of the side assemblies preassembled by the pre-buck unit. Finally, the system posts assemble vehicle body components to the upper portions of the side assemblies by second welding robot.
US Patent 11478882
CANON KABUSHIKI KAISHA
Simplifying image pickup posture determination with this apparatus
What is this invention?
Image processing apparatus that processes image picked up by image pickup apparatus attached to robot, control method therefor, and storage medium storing control program therefor
There once was an image processing app
That used teaching point information to map
The working area of a robot
And the image pickup area too
So determining the posture was much easier for it.
Do you ever find yourself wishing you could just snap a picture of the robot's current position and be on your way? Well, with today's technology you can! The CANON KABUSHIKI KAISHA Image Processing Apparatus is designed to simplify operations for determining an image pickup posture of an image pickup apparatus attached to a robot. By processing an image that the image pickup apparatus picks up, this device can quickly and easily determine where it should be positioned to capture the best possible shot. Simply specify a working area on the robot based on teaching point information and let the device take care of everything else - including specifying an image pickup area that includes the specified working area. With this simple process, you'll be able to get accurate images every time without all of the hassle!
The image processing apparatus includes a memory device that stores a set of instructions, and at least one processor that executes the set of instructions to specify a working area of the robot based on teaching point information showing a plurality of designated teaching points, specify an image pickup area of the image pickup apparatus so as to include the specified working area; and determine an image pickup posture of the robot based on the specified image pickup area.The teaching point information can be used to simplify operations for determining an image pickup posture. For example, if you know where your hands are in relation to your body when taking pictures or video, it is much easier to orient your camera in those same positions when using this type of apparatus.
US Patent 11478936
Hyundai Motor Company
Symbol Button Manufacturing Method Provides Durable, Stunning Design
What is this invention?
Symbol button for vehicle and manufacturing method thereof
There once was a method for making
A symbol button out of polymer.
First you form the body,
Then add a conductive layer,
And finally shield it with metal plating.
Hyundai Motor Company has released a new symbol button for vehicles! This innovative product allows drivers to easily identify their vehicle and ensure accuracy when towing. The button body is made of a polymer material and is coated with an electrically conductive layer. This layer is then used to create a plating shielding layer in the form of a symbol. Next, metal is plated onto the outside of the button body, creating a durable and accurate symbol. With this new product, drivers will no longer have to worry about misplacing or losing their tow Symbol buttons!
The patent describes a manufacturing method for a symbol button for use on a vehicle. First, the button body is prepared comprising a side portion and top portion formed of a polymer material. An electrically conductive layer is then formed on the outside of the button body using a conductive polymer material. A plating shielding layer in the form of a symbol is then formed using a material on which metal is not able to be plated. Finally, metal plating is performed on the outside of the button body having the plating shielding layer.
US Patent 11478963
GM GLOBAL TECHNOLOGY OPERATIONS LLC
New Method for Making Composite Articles
What is this invention?
Systems and methods of making a composite article
The methods for making a composite article
Are provided herein, so you can start right
Unwinding the fiber substrate material
And impregnating with an uncured resin
Will result in a resin-fiber material
Which you can then wind onto a shaped surface
Heating it up to initiate an exothermic reaction
Will cause polymerization, cross-linking, or both
Temperature must be monitored during this process
So that the operating polymerization front velocity is kept the same as the set point
The methods of making a composite article are provided herein. The method can include an unwinding step including unwinding a fiber substrate material from a creel at an unwinding velocity and an impregnation step including applying an uncured resin composition to the fiber substrate material to form a resin-fiber material. The method further includes a winding step comprising applying the resin-fiber material onto a shaped surface at a winding velocity and a solidifying step comprising applying heat to the resin-fiber material to initiate an exothermic reaction comprising polymerization, cross-linking, or both of the uncured resin composition. Temperature of the resin-fiber material can be monitored during operation of the method and a polymerization front velocity set point (vpfs) and an operating polymerization front velocity (vpfo) can be determined. Parameters can be adjusted to maintain a vpfo that is substantially the same as the vpfs. Systems for performing said methods are also provided.
US Patent 11478978
Canon Kabushiki Kaisha
Printing Apparatus with Heating Element that Prevents Temperature from Exceeding Preset Threshold
What is this invention?
Liquid discharging head
The printing apparatus includes a substrate
With a heating element to make it hot;
When the temperature detecting element
Finds the preset threshold has been met,
The heating enabling signal is sent
So that liquid can be discharged from the pot.
Canon Kabushiki Kaisha has released a new printing apparatus that is sure to revolutionize the way you print! The Liquid Discharging Head prints by discharging liquid onto a substrate using a heating element. This system has many benefits over traditional methods of printing, such as high speed and accuracy. Not only does this technology produce great prints quickly, but it also eliminates the need for waste ink cartridges and reduces environmental impact. If you're looking for an innovative and environmentally friendly way to print your documents, then look no further than the Canon Kabushiki Kaisha Liquid Discharging Head!
The printing apparatus includes a substrate including a heating element for heating and discharging liquid, and a temperature detecting element for detecting a temperature of the substrate. The detection period extends across a plurality of cycles of the latch signal, and the heating enabling signal for discharging the liquid and the latch signal are output such that, in the detection period, an output value of a temperature waveform does not exceed a preset threshold value. The temperature waveform is a temperature waveform of the substrate detected by the temperature detecting element.
US Patent 11479037
GM Global Technology Operations LLC
NEW Jounce Shock System Keeps Your Vehicle in Suspension Mode
What is this invention?
Top mount with integrated jounce damper
There once was a car with great suspension
It had a jounce shock assembly for cushion
The top mount body had an interior cavity
And the floating piston was movably disposed
The vehicle suspension system includes a damper top mount including a top mount body defining an interior cavity, a damper coupled to the top mount and including a damping member and a damper rod coupled to the damping member, and a jounce shock assembly including a jounce shock body coupled with the damper top mount and encircling the top mount body. The jounce shock body includes an exterior wall and a dividing wall generally parallel to and interior of the exterior wall, first chamber defined by the top mount body and the dividing wall, second chamber fluidly coupled with and parallel to the first chamber and defined by the dividing wall and the exterior wall, floating piston movably disposed within the second chamber, and piston configured to translate within the first chamber between an extended position and a compressed position.
US Patent 11479072
GM GLOBAL TECHNOLOGY OPERATIONS LLC
Control System Provides Enhanced Safety by Adjusting Suspension Based on Moving Vehicles
What is this invention?
Vehicle body roll reduction
There once was a car with great suspension
That could handle any terrain or condition
With sensors to measure speed and location
It knew just how to keep itself in motion
So whether you're off-roading or on the street
This car will give you one heck of a ride!
If you're looking for a way to improve your vehicle's handling, then you need to check out the GM Global Technology Operations LLC suspension system controller. This amazing piece of technology uses sensors to detect other vehicles and their movements in relation to your own. As a result, it is able to automatically adjust your suspension system in order to provide even better control and stability on the road. Not only does this make driving much more enjoyable, but it can also help reduce the risk of accidents. If you're interested in giving this system a try, be sure to contact one of our experts today!
In various embodiments, methods and systems for controlling a suspension system of a vehicle are provided. In one embodiment, a control system includes: one or more first sensors configured to measure a velocity of the vehicle; one or more second sensors configured to detecting one or more additional vehicles that are moving in relation to the vehicle; and a processor that is coupled to the first sensors and the second sensors and that is configured to provide instructions for adjusting the suspension system of the vehicle, based on the measured velocity of the vehicle and the detected one or more additional vehicles that are moving in relation to the vehicle.
US Patent 11479073
HYUNDAI MOTOR COMPANY
A Heat Pump System Controls Battery Module Temperature
What is this invention?
Heat pump system for vehicle
There once was a heat pump system
That controlled the temperature of a battery module
With one chiller that used a refrigerant and coolant
To heat-exchange and recover waste heat
This improved the heating performance and efficiency
Looking to improve your vehicle's heating performance and efficiency? Check out this amazing innovation from Hyundai Motor Company! The Heat Pump System for Vehicle uses one chiller to heat up a battery module, recovering waste heat generated from other electrical components and the battery itself. This system then increases the flow rate of refrigerant by applying a gas injection part that selectively operates in the heating mode of your vehicle - maximizing its ability to heat up your car or truck quickly and efficiently. Whether you're looking for an upgrade to help combat cold weather conditions or just want to save on energy costs, this is an essential product for anyone who owns a vehicle.
A heat pump system of a vehicle controls a temperature of a battery module by using one chiller in which a refrigerant and coolant are heat-exchanged, and recovers waste heat generated from an electrical component and battery module to use it for indoor heating, thereby improving heating performance and efficiency. The heat pump increases the flow rate of the refrigerant by applying a gas injection part that selectively operates in the heating mode of the vehicle. This maximizes heating performance.
US Patent 11479076
Hyundai Motor Company
Multi-Zone Air Conditioner System Keeps Your Vehicle Cool
What is this invention?
Multi-zone air conditioner system for large vehicles and control method thereof
There once was a device quite nifty
For large vehicles, it was quite a hit-tee
It could partition the space
Into zones of cool air; and with grace
The driver could adjust as they saw fit-tee
Do you ever feel like your car just isn't as cool as it used to be? Maybe it's summertime and the windows are starting to stick, or maybe you're driving in a hot city. No matter the reason, sometimes air conditioning simply isn't enough. That's where this amazing innovation comes in - the Hyundai Multi-Zone Air Conditioner System for Large Vehicles! This system allows drivers to individually control each zone of their car's air conditioning, ensuring that everyone is comfortable no matter what the temperature might be. Plus, since this system uses solar radiation detection, it can even adjust its settings based on outside conditions! So whether you're stuck in traffic or trying to beat the heat, this system has your back.
The invention described herein is a multi-zone air conditioner system for large vehicles. The system includes an air conditioning device configured to partition an internal of the vehicle into a plurality of zones to independently cool each zone, a detecting device configured to include a room temperature detector for detecting a room temperature of each zone and a photo detector for detecting an amount of solar radiation, an input device configured to switch the operating state of the air conditioning device to either automatic or manual modes, and a control device configured to generate a control signal for operating the air conditioning device based on signals transmitted from the detecting device and input device.
US Patent 11479078
HYUNDAI MOTOR COMPANY
Fuel Door Opener Assembly Locks or Unlocks Your Vehicle's Fuel Door
What is this invention?
Fuel door opener assembly
There once was an assembly for fuel
Its opener housing had a heart-shaped cam
The locking block was slidably installed
And the locking pin could be positioned as needed
All thanks to the elastic member inside the housing
Do you ever find yourself struggling to unlock your car's fuel door in a hurry? The problem is usually due to the fact that the locking pin can become stuck on the heart-shaped cam. This happens because the locking block is prevented from moving along the cam by the elastic member. Fortunately, there is now a solution! Hyundai has developed a new fuel door opener assembly that includes a locking block that can be easily moved along the cam thanks to its elastomeric support. This means that you will no longer have to struggle with getting your pin into position - it will do it for you! If you are looking for an upgrade or just want something that makes life easier, this is definitely one product worth considering.
The patent describes a fuel door opener assembly that includes an opener housing, a locking block slidably installed inside the opener housing, and a locking pin configured to be moved along a heart-shaped cam formed on the locking block to restrict a location of the locking block in accordance with a position thereof on a profile of the heart-shaped cam. The elastic member is disposed in the opener housing and elastically supports the locking pin to allow it to be positioned on the profile of the heart-shaped cam.
US Patent 11479113
Hyundai Motor Company
Fuel Cell Vehicle Mounted Rearward to Save Fuel
What is this invention?
Fuel cell vehicle
There once was a fuel cell vehicle
That had its front fuel cell mounted in a space
The rear fuel cell was located at the back
Which allowed for increased storage capacity
And easier access to components
Hyundai Motor Company has released a new fuel cell vehicle that is sure to revolutionize the way we think about transportation. The Fuel Cell Vehicle, or FCV for short, is designed to be environmentally friendly and efficient. Not only does it have the potential to reduce our dependence on fossil fuels, but it also offers a unique driving experience. The FCV features two fuel cells - one located at the front and one located at the rear - which are strategically placed so that they can best utilize available space. This allows for a smooth and comfortable ride, no matter where you're going. With its cutting-edge technology and sleek design, Hyundai has once again set the standard for innovation in fuel cell vehicles.
The fuel cell vehicle disclosed includes a front fuel cell mounted in a first space and a rear fuel cell mounted in a second space located at the rear side of the first space on the basis of the direction in which the fuel cell vehicle travels. The rear fuel cell includes a top surface lower than the top surface of the front fuelcell on the basis of the ground. This allows for easier access to components and increased storage capacity.
US Patent 11479130
HYUNDAI MOTOR COMPANY
Automatic Charging for Your Vehicle - Stay Connected!
What is this invention?
Apparatus and method for automatically charging a vehicle
There was an apparatus made for charging cars
It had a manipulator and a processor
With power supply connected to the plug
It could charge up any car with a single tug
Making sure that batteries never ran too far!
Do you ever find yourself in a situation where you need to charge your vehicle but don't have access to an outlet? Well, worry no more! This innovative charging system from Hyundai will take care of everything for you. Simply park your car near the charging port and let the processor do its magic - it will automatically detect your vehicle and calculate its position, allowing it to connect the charging plug accordingly. Not only is this system incredibly convenient, but it also saves you time - no more waiting around for hours on end while your battery slowly drains. If you're looking for a way to improve your overall driving experience, then look no further than this ingenious charging system!
The apparatus and method for automatically charging a vehicle include a charging plug to connect to a charging port of the vehicle, a manipulator to move the charging plug to the charging port of the vehicle, a power supply connected with the charging plug to supply charging power to the vehicle, and a processor.
US Patent 11479136
Hyundai Motor Company
Drive Your Way to Fun with a Variable Body Vehicle
What is this invention?
Variable body vehicle
There once was a car with no motor
Which ran on electric power
With a battery mounted inside
It could go far and wide
This variable body vehicle
Hyundai Motor Company has released a new variable body vehicle that is sure to revolutionize the way we think about transportation. The Variable Body Vehicle (VBM) allows for a variety of configurations and purposes of use, making it perfect for any type of driver. With the ability to drive using electric power alone or in combination with traditional gasoline or diesel engines, this vehicle is able to do it all! Whether you need a car that can accommodate your family and groceries or one that can handle long distances with ease, the VBM has you covered. So what are you waiting for? Give Hyundai a call today and see how this amazing vehicle can change your life!
A variable body vehicle may include a drive module having drive the vehicle wheels provided at a lower portion of the drive module; a body module coupled to an external side of the drive module and forming an internal space of the vehicle; and a battery-mounting portion formed in the drive module or the body module to mount a battery therein, providing electric power to the battery when the battery is mounted, and determining a driving mode of the vehicle by allowing the battery to be selectively mounted in the drive module. The body of the vehicle is variable by a combination between the drive module and the body module according to a purpose of use.
US Patent 11479143
Ford Global Technologies, LLC
Vehicle occupancy management systems and methods - See how to detect passengers and assign seating in your car
What is this invention?
Vehicle occupancy management systems and methods
There once was a car with no driver
That used an occupancy management system
It could detect a passenger inside
And determine where they should sit tight
So the seat map would be generated right
Do you ever find yourself wishing you could just magically transport more people into your car? Well, Ford has got your covered! Their new Vehicle Occupancy Management Systems and Methods allow drivers to seat as many passengers as they'd like in their vehicle with ease. Simply by detecting the presence of at least one passenger in the car using a camera, the system will generate a seat map that identifies where that person is seated. This makes it easy to move any extra passengers around without having to worry about rearranging all of your furniture - perfect for when you need to take a few friends along on your weekend getaway but don't have enough room inside the car! With so many new options available for transportation these days, it's important to have systems like this at our disposal. Who knows, maybe someday we'll all be able to ride shotgun without feeling cramped or uncomfortable!
The patent provides an overview of vehicle occupancy management systems and methods. The system can detect at least one passenger in the vehicle, and determine a seating location for the passenger. The seat map can then be generated that identifies the seating location for the passenger.
US Patent 11479147
HYUNDAI MOBIS CO., LTD.
Device Controls Airbag Deployment
What is this invention?
Device and method for controlling airbag
There once was a car with an airbag
That was controlled by a fancy new fag
It could sense when you're crashing
And would deploy in a flashin'
So you'll never again need to say "Ouch!"
Are you worried about the safety of your passengers in the event of a collision? With this new airbag control system from Hyundai Mobis, you can rest assured that your passengers will be safe even if something goes wrong. The system uses a variety of sensors to detect surrounding vehicle information and collision information of the ego-vehicle. This data is then used to calculate a target relative velocity and TTC based on sensing information detected by the first sensor unit. Collision risk is then determined based on this data, and a threshold for airbag deployment is maintained by default or adjusted accordingly. If collision information received from the second sensor unit indicates that there is an increased risk of injury, then the airbag may be deployed automatically. This system provides peace of mind during dangerous driving conditions, and ensures that everyone in your car remains safe!
The disclosed device is a control system for controlling an airbag. The system includes a first sensor unit configured to detect surrounding vehicle information using at least one sensor, and a second sensor unit configured to detect collision information of an ego-vehicle using at least one sensor. The controller is configured to calculate a target relative velocity and time to collision (TTC) based on sensing information detected by the first sensor unit, determine a collision risk of the ego-vehicle based on the calculated target relative velocity and TTC, maintain a threshold for airbag deployment by default or adjust the threshold, based on a result of the determination of the collision risk of the ego-vehicle, compare the maintained or adjusted threshold with the collision information received from the second sensor unit, and control whether to deploy the airbag based on whether the collision information is maintained or adjusted.
US Patent 11479196
FORD GLOBAL TECHNOLOGIES, LLC
Vehicle Includes Airbags That Inflate With Tether Connected
What is this invention?
Console airbag
There once was an assembly with two airbags
That could inflate to protect from any crashes
The first bag had a top that was distal
While the second's top was much closer and more central
With a tether connecting the two for extra safety
A vehicle includes an assembly having a middle console and two airbags that are inflatable upwardly from the middle console to an inflated position. The first airbag has a top distal to the middle console in the inflated position, while the second airbag has a top proximate to the middle console in the inflated position. A tether is external to both airbags and connects each bag's top to one another.
US Patent 11479200
Hyundai Mobis Co., Ltd.
LiDAR Sensor Delivers a Clean Window View
What is this invention?
LiDAR sensor
There once was a sensor called LiDAR
Whose window cover needed a repair
The motor was mounted
Inside the housing, and
The guide was formed in a U-shape
Hyundai Mobis Co., Ltd. has released a new LiDAR sensor that is sure to revolutionize the way drivers operate their towed vehicles! The LiDAR sensor includes a rotating shaft and guide connected to it, which allows the brush to rotate while it washes the surface of the window cover. This innovative design eliminates any need for manual labor in order to keep your trailer in line - making your tow job much easier! Not only does this system make tow driving much simpler, but it also saves you time and energy. If you're looking for an easy solution that will improve your overall tow experience, then be sure to check out Hyundai Mobis Co., Ltd.'s latest product!
A LiDAR sensor may include a housing, a window cover installed on the housing, a motor mounted in the housing, a rotating shaft rotated by the motor, and a guide connected to the rotating shaft and rotated along the surface of the window cover. The guide may include a first guide part connected to the rotating shaft, a second guide part rotatably connected to the housing, and a third guide part connected to the first and second guide parts, formed in a U-shape so as to face the window cover. The brush mounted on the guide so as to face the window cover contacted with it rotate with rotation of the guide.
US Patent 11479214
Ford Global Technologies, LLC
Braking Distance Based on Speed in Adjacent Lane
What is this invention?
Adaptive cruise control
There once was a driver quite wary
Who used a system to help make it clear-y
When the car in front stopped short
Their own brakes would abort
Preventing a nasty collision, most definitely!
Are you looking for a way to improve your safety on the road? Check out Adaptive Cruise Control! This innovative technology uses sensors within your car to detect other vehicles and calculate an appropriate braking distance. If you are ever within this range, the primary vehicle's braking system will be activated. This is a great way to prevent accidents and keep yourself and others safe on the road. With so many new cars coming equipped with this technology, it is important that you learn how to use it properly. Not only will this help you stay safe, but it could also save you time and money in the long run. Give Adaptive Cruise Control a try today!
The system described herein includes a computer with executable instructions that determine a braking distance based on a gap distance between a primary vehicle and a second vehicle in an adjacent lane, and based on the speed of the second vehicle in the adjacent lane. When the primary vehicle is within this braking distance from a third vehicle in the same lane as the primary vehicle, then the braking system of the primary vehicle is automatically activated. This system can be beneficial for preventing collisions between vehicles by enabling drivers of these vehicles to take appropriate action sooner than they would otherwise be able to.
US Patent 11479220
HYUNDAI MOTOR COMPANY
Brake System Can Form Negative Pressure
What is this invention?
System and method for forming brake negative pressure
There once was a brake system so fine
With an engine, a vacuum, and turbocharger line
The pressure was negative, of course
But the Source Selection apparatus had to be force
To open and close based on the compressor's design
Brake systems are essential for any vehicle, and especially so for trucks and SUVs. In order to provide the best possible braking performance, it is important to have a system that can form negative pressure in a reservoir. This type of system is commonly referred to as a brake negative pressure (BNP) system. The Hyundai Motor Company has developed an innovative system that allows you to control both the pump negative pressure and intake negative pressure lines based on the operation of your turbocharger. By doing this, you can ensure that your brakes are always performing at their best!
The system for forming a negative pressure in a brake system includes an engine, a vacuum pump, a turbocharger, and a pump negative pressure line. The engine generates intake negative pressure. The vacuum pump supplies the pump negative pressure to the negative pressure reservoir. The turbocharger supplies compressed air to the engine. The pump negative pressure line connects the vacuum pump and the negative pressure reservoir. The intake negative pressure line connects the negative pressure reservoir and the intake manifold. And, the Negative Pressure Source Selection apparatus controls opening and closing of the pumpnegative line and the intakenegative line based on operation of the turbocharger.
US Patent 11479223
HYUNDAI MOBIS CO., LTD.
Vehicle Lane Change Control Apparatus Provides Corrected Rate for Safe Lane Changes
What is this invention?
Vehicle lane change control apparatus and method
There once was a driver quite skilled
Who could change lanes with great speed and precision
But when they were tired
Their lane changes were mired
In traffic and led to collision
Do you ever find yourself constantly changing lanes, but never quite getting where you want to go? Well, with this new invention by Hyundai Mobis Co., Ltd., that problem may be a thing of the past! The Vehicle Lane Change Control Apparatus and Method allows drivers to change lanes with ease, regardless of traffic conditions. This system uses condition information (such as speed and heading) from sensors within the vehicle to determine when it is safe to make a lane change. Once determined, the control unit will adjust your steering accordingly in order to keep you on track. If you ever find yourself stuck in traffic, give this system a try - it could save you some time and hassle!
The vehicle lane change control apparatus includes a condition information acquisition unit that acquires condition information of an occupant of a vehicle, a lane change rate database unit that stores a lane change rate that is determined based on a lane change pattern of the driver analyzed based on driving information when the lane of the vehicle is changed and road condition information when the lane of the vehicle is changed and indicates a speed of the lane change.
US Patent 11479252
HYUNDAI MOBIS Co., Ltd.
Ego Vehicle Travels Safely and Efficiently with Automatic Map Navigation
What is this invention?
Autonomous driving apparatus and method
There once was an autonomous car
That could travel near and far
With a first sensor to detect
And map info in memory to direct
It provided safe transport for those not up to the task!
This article describes an autonomous driving apparatus and method for an ego vehicle that autonomously travels. The apparatus includes a first sensor to detect a nearby vehicle, a memory to store map information, and a processor to control autonomous driving of the ego vehicle based on the nearby vehicle detected by the first sensor and the map information stored in the memory.
US Patent 11479267
Hyundai Mobis Co., Ltd.
A Simple and Efficient Torque Compensation Apparatus for MDPS Systems
What is this invention?
Torque compensating apparatus and method for motor driven power steering system
This torque compensation apparatus is great
For a Motor Driven Power Steering system
It includes a column torque sensor to detect
The column torque applied to the steering shaft
And a steering angle sensor to detect
The steering angle of the steering wheel
Have you ever had to make a sudden steering adjustment while driving, only to find that your MDPS system was not providing the desired level of assistance? If so, then you are not alone. In fact, this is one of the most common problems with MDPS systems. The reason for this is that these systems rely on a basic assist torque outputted from the system in order to provide assistance during sudden steering adjustments. However, if this assist torque is not sufficient, then users will have to make frequent and unnecessary adjustments in order to maintain their desired trajectory. This article will discuss an innovative new torque compensating apparatus designed specifically for MDPS systems. By calculating a compensation ratio based on both column torque and steering angular velocity, this apparatus can ensure that the basic assist torque always provides the necessary level of assistance during sudden steering adjustments. So whether you're driving down the highway or making a quick turn in your driveway - be sure to keep your MDPS system equipped with this ingenious new invention!
This torque compensation apparatus is for a Motor Driven Power Steering (“MDPS”) system. The MDPS system includes a column torque sensor configured to detect column torque applied to a steering shaft, a steering angle sensor configured to detect a steering angle of a steering wheel, and a controller configured to calculate a compensation ratio by sudden steering, based at least one of the column torque detected by the column torque sensor and the steering angular velocity calculated from the steering angle detected by the steering angle sensor. The basic assist torque outputted from the MDPS system is then compensated for according to the compensation ratio.
US Patent 11479292
Hyundai Motor Company
Steering System Provides Active Control of Torsional Rigidity
What is this invention?
Steering system of vehicle
There was a car with some nifty tech--
it had an MR assist device.
The steering system could change on a dime,
and the torsion bar was alive.
If you're in the market for a new steering system for your vehicle, be sure to check out the Hyundai Motor Company's MR assist device. This innovative technology allows the torsion bar to remain rigid even under heavy loads or during driving conditions that would otherwise cause it to buckle. By using an MR fluid as a working fluid, this system is able to adjust the rotation and torsional rigidity of the torsion bar without any limitations. Not only does this provide increased stability and durability, but it also ensures that your vehicle remains in control during all types of conditions. If you're looking for a steering system that will handle any situation head on, be sure to give the Hyundai Motor Company's MR assist device a try!
The steering system of the vehicle adjusts the torsional rigidity of a torsion bar without limitation as to the configuration thereof and performs active control responding to the vehicle state by adjusting steering characteristics by controlling the torsional rigidity of the torsion bar based on the traveling condition, load state or driving mode of the vehicle. The MR assist device is coupled to an end portion of the torsion bar and adjusts its rotation and torsional rigidity using an MR fluid as a working fluid.
US Patent 11479294
GM Global Technology Operations LLC
An Energy Absorber Keeps Objects From Colliding
What is this invention?
Tunable energy absorber
There once was an energy absorber
That interposed between a cover
And a covered object
To protect with its deceleration
From any impulse or commotion.
The patent describes an energy absorber for interposing between a cover and a covered object. The energy absorber includes a matrix of cells with each cell having a respective energy absorption capacity such that the energy absorption capacity of the energy absorber varies across at least one direction. Impulse of an object with the cover with the energy absorber sandwiched between the cover and the covered object causes a deceleration vs. time response in the object, beginning with a generally linear rise in the deceleration to a peak deceleration within 5 ms after the beginning of the impulse event, followed by a generally nonlinear decrease in the deceleration over a period of not greater than 15 ms to a final target deceleration of not greater than 10% of the peak deceleration.
US Patent 11479304
CANON KABUSHIKI KAISHA
The New Sheet Feeding Apparatus: It's Easy to Feed Your Papers with One Hand!
What is this invention?
Sheet feeding apparatus and image forming apparatus
There once was a sheet feeding apparatus
That included a sheet supporting portion
A feeding member would contact the upper surface
And feed the sheet with great force
But if you rotated the drive motor in the other direction
The lifting mechanism would also work in that direction
Looking for an innovative way to feed sheets of paper into your printer? Look no further than the Canon Sheet Feeding Apparatus! This handy device allows you to feed sheets of paper directly into your printer without having to use a manual input tray. Simply place the sheet feeding apparatus on top of your printer and press the start button. The machine will automatically adjust its position and begin feeding the sheet of paper into your printer. If you need to stop feeding the sheet, simply press the stop button. This ingenious design makes it easy to get consistent prints every time!
The sheet feeding apparatus includes a sheet supporting portion to support a sheet, a feeding member to contact an upper surface of the sheet supported on the sheet supporting portion and feed the sheet, and a drive motor to rotate in two directions opposite one another. The lifting mechanism is connected to the drive motor so that it can lift the sheet supporting portion and lower the feeding member in cases where the drive motor rotates in one direction (the first direction), and also lift and lower the feeding member in cases where the drive motor rotates in another direction (the second direction) opposite to the first direction.
US Patent 11479423
Canon Kabushiki Kaisha
One-Way Clutch Lets You Drive Without Gear
What is this invention?
One-way clutch, sheet conveying apparatus, and image forming apparatus
There once was a one-way clutch
With an inner periphery and an internal gear
The inner member was rotatably disposed
And had an engagement portion
While the planetary gear was prevented from rotating by engaging with the engagement portion
The patent describes a one-way clutch. The outer member has an inner periphery including an internal gear, the inner member is rotatably disposed, and includes an engagement portion, and the planetary gear is rotatable relative to the inner member, meshes with the internal gear, and is prevented from rotating by engaging with the engagement portion. In a state in which the outer member and the inner member rotate together, the planetary gear engages with the engagement portion. In a state in which relative rotation between the outer member and the inner member is performed, the planetary gear disengages from the engagement portion. And in a state in which the planetary gear engages withthe engagement portion, a top land ofthe internalgear abuts on a bottom land ofthe planetarygear.
US Patent 11479425
