Most innovative companies for 11/15/2022 (new inventions)
Exciting new inventions from International Business Machines Corporation, Honda Motor Co., Ltd., Hamilton Sundstrand Corporation, Canon Kabushiki Kaisha And Hyundai Motor Company
This is a weekly article summarizing a handful of inventions from the most innovative companies in the world. The summaries are created by an A.I. and proof-read by a human before publication. Attempts are made to ensure accuracy of the descriptions, but it is very much a work in progress. Each invention description is preceeded by a poem about the invention that is written by the A.I. I have found the limerick is actually quite good at explaining the invention in simple terms. Enjoy!
International Business Machines Corporation
Porous Substrates Expose Themselves to Pressure for Functionalization
What is this invention?
Selectively functionalized porous material
International Business Machines Corporation has invented a new type of porous substrate that is susceptible to both hydroxylation and alkoxylation by a first protic solvent. With this new substrate, you can selectively functionalize one or both of the pores on the surface to create a modified porous substrate that is much more resistant to degradation. This modified substrate can then be reacted with a specific functionalizing reagent to create a functionalized porous substrate that is even more durable and stable.
A porous substrate is exposed to a first relative pressure of a protic solvent. This pressure is effective to one or both of hydroxylate and alkoxylate pores of the substrate's average pore diameter. The porous substrate includes a first plurality of pores having a first average pore diameter and a second plurality of pores having a second average pore diameter that is greater than the first average pore diameter. The first relative pressure is also effective to functionalize only the pores in the first average pore size range, thereby forming a modified porous substrate. Next, a first functionalizing reagent is used to functionalize one or both of hydroxylated or alkoxylated surfaces on the modified porous substrate. Finally, this functionalized substrate is reacted with another reagent that will cause it to polymerize into an article.
US Patent 11498063
INTERNATIONAL BUSINESS MACHINES CORPORATION
A Rapid Test Device for Chemical Testing
What is this invention?
Rapid testing device for wastewater analysis
With so many different types of tests that can be performed on wastewater, it is important to have a rapid test device that can handle all of them. The INTERNATIONAL BUSINESS MACHINES CORPORATION Rapid Testing Device for Wastewater Analysis is just that - a device that can quickly test multiple parameters on wastewater samples. This versatile tool has a micropad chip that is configured for multi-parameter chemical testing, and it also includes filtering, sample absorption, and distribution elements to help with the process. Plus, colorimetric results are displayed on an element in fluid communication with the reacting elements, which makes it easy to see what chemicals are being tested and how they are reacting. With this device at your disposal, you'll be able to quickly get accurate results for all your wastewater testing needs.
A rapid test device includes a micropad chip configured for multi-parameter chemical testing. The micropad chip includes a plurality of paper layers in fluid communication, including a sample absorption element, a filtering element configured to filter the input sample, and a sample distribution element configured to distribute the input sample received from the filtering element to a remainder of the plurality of paper layers. One or more reacting elements associated with the multi-parameter chemical testing of the input sample have one or more colorimetric reagents in fluid communication with the sample distribution element. A colorimetric result displaying element in fluid communication with the one or more reacting elements is configured to display a colorimetric result of the testing of the input sample with the at least one reacting element for a respective chemical test of the multi-parameter chemical testing.
US Patent 11498069
HONDA MOTOR CO., LTD.
Work Machine with Heat Exchanger
What is this invention?
Work machine
There once was a work machine
That had a lubricating oil channel
And a working fluid channel
For supplying a working fluid to a work unit
So that heat could be exchanged between the two
With summertime coming to a close, many people are starting to prepare for the colder months ahead. One of the things that you may need to do in order to keep your engine running smoothly during the cold months is to reserve some lubricating oil. Work machines like this one from Honda Motor Co., Ltd. can help you do just that by allowing heat to be exchanged between the lubricant and working fluid so that everything stays in good condition. Not only does this make your engine run smoother, but it also prevents wear and tear on other parts of the machine - something that you will definitely appreciate come wintertime!
The work machine includes a lubricating oil channel and a working fluid channel for supplying a working fluid to a work unit. The lubricating oil channel and the working fluid channel are arranged such that heat can be exchanged between the lubricating oil and the working fluid.
US Patent 11498088
Hamilton Sundstrand Corporation
Fabricate Near Net Shape Components with Sacrificial Shell
What is this invention?
Method for fabricating components using hybrid additive manufacturing and consolidation process
There once was a method for making things
With near net shapes using additive manufacturing
A sacrificial shell would be formed from pulverant material
Then filled with a second pulverant material
The shell would then be subjected to consolidation
Which resulted in the removal of the shell
This allowed for the fabrication of components
That were difficult or impossible to make using traditional methods
Additive manufacturing is a process that has been used to create 3D objects from digital files for years now. But what if you want to create a component that's not quite shaped like a traditional part? That's where hybrid additive manufacturing comes in - it allows you to fuse together two different types of materials to form the final product. In this article, we'll take a look at how Hamilton Sundstrand Corporation's Method for fabricating components using hybrid additive manufacturing and consolidation process works.
The patent describes a method for fabricating components with near net shapes using additive manufacturing. A sacrificial shell is formed from a pulverant material, and is filled with a second pulverant material. The shell is then subjected to a consolidation process, which results in the removal of the shell from the consolidated second pulverant material. This method allows for the fabrication of components with near net shapes that are difficult or impossible to manufacture using traditional methods.
US Patent 11498125
Canon Kabushiki Kaisha
A Teaching Device Lets You Correct Your Robot's Moving Path in Virtual Space
What is this invention?
Teaching device, teaching method, and robot system
There was a device for teaching
That acquired information about geometrical errors
Between virtual 3D models--this
Correction unit then used to fix
The robot's moving path, so it wouldn't be a bother.
Canon Kabushiki Kaisha has come up with a new teaching device that will help you to better understand the geometry of your 3D models. The Canon Kabushiki Kaisha Teaching Device allows you to construct a virtual robot system in which a virtual 3D model of the robot and a virtual 3D model of its peripheral structure are arranged. By correcting the moving path of the robot in accordance with information about the geometric error between these two models, this device can help students to improve their understanding of robotics mechanics.
The teaching device includes an acquisition unit that acquires information about a geometric error between the virtual 3D models. The correction unit corrects the moving path of the robot in accordance with the information acquired by the acquisition unit.
US Patent 11498214
International Business Machines Corporation
Transitioning Structures with Shape Memory Materials
What is this invention?
Shape memory materials with reversible transitions
There once was a structure quite nifty
With shape memory materials so shifty
It could transition between states
Depending on the triggers it fatefully meets
And existed in three physical shapes, reversibly!
With the invention of shape memory materials, it has become possible to create structures that are both physically and reversible. International Business Machines Corporation (IBM) has unveiled a new system that uses these materials to create three different physical shapes - all of which can be returned to their original state with just a few simple steps. This innovative technology could have a huge impact on many industries, from medical devices to manufacturing.
This document discloses aspects of a structure that includes shape memory materials having transition triggers to transition the shape memory materials between initial states and transitioned states. A first physical shape of the structure exists when the first shape memory material has the first initial state and the second shape memory material has the second initial state. A second physical shape of the structure exists when the first shape memory material has the first transitioned state and the second shape memory material has the second initial state. A third physical shape of the structure exists when the first shape memory material has the first transitioned state and the second Shape Memory Material hasthe second transitioned state. The physical shapes of this structure are reversible in nature. In embodiments, theseshape memory materials are bonded to a flexible substrate or they are clad together.
US Patent 11498307
CANON KABUSHIKI KAISHA
High Sensitivity Element Substrate Detects Liquid Behavior
What is this invention?
Element substrate, liquid discharge head, and printing apparatus
There once was an element substrate
That could detect the behavior of a liquid
It had a first electrothermal transducer
And at least one temperature detection element
So it could generate heat in association with a temperature detection operation
Detecting the behavior of a liquid is an important task, and with today's technology, it's easier than ever before. Element substrate, according to an embodiment of this present invention, is capable of detecting the behavior of a liquid at a high sensitivity - making it perfect for use in various applications.First electrothermal transducer generates heat to discharge the liquid while at least one temperature detection element nearby monitors the temperature. If the temperature reaches a certain level, then second electrothermal transducer will start generating heat in association with the temperature detection operation. This allows for accurate measurements even under difficult conditions.
An element substrate, according to an embodiment of this present invention, capable of detecting the behavior of a liquid at a high sensitivity comprises: a first electrothermal transducer configured to generate heat to discharge the liquid; at least one temperature detection element arranged near the first electrothermal transducer; and a second electrothermal transducer configured to generate heat in association with a temperature detection operation by the at least one temperature detection element.
US Patent 11498333
Canon Kabushiki Kaisha
New Inks Tank Protrudes From Ink Storage Port To Keep Ink Flowing Smoothly
What is this invention?
Ink tank and leakage inspection method for ink tank
There was an ink tank with a damper
That also had a protruding member.
When viewed from the side,
The damper did hide
The communication hole, which was rather a bummer.
Ink tanks have always been a vital part of any printer, and their design has evolved to meet the needs of today's printers. Canon Kabushiki Kaisha has introduced an ink tank that features a flexible damper portion that can communicate with an inside of the ink storage portion through a communication hole - making it easier than ever before to inspect for leaks.
The patent describes an ink tank that includes a flexible damper portion and a protruding portion. The protruding portion is formed in the inside of the damper portion, and when viewed from a direction in which it protrudes, the damper portion surrounds an entire circumference of the communication hole. The opening portion is formed in the protruding portion.
US Patent 11498338
CANON KABUSHIKI KAISHA
Printing Apparatus Sends Order Request for Consumable in Case of Exceeding Degree
What is this invention?
Printing apparatus with contract related ordering, ordering system, and control method
There once was an apparatus for printing
That had a sending unit to help with ordering
When the consumable condition
Exceeded a certain degree,
The request would be sent out based on information.
With so many contracts out there, it can be hard to keep track of which ones still have some time left - and which ones have already expired. That's where the ordering apparatus in this new Canon printing apparatus comes in handy. By sending an order request for a consumable that exceeds its degree of use by a predetermined amount, you can ensure that your business stays stocked up on the necessary supplies. Plus, with a contract expiration date close at hand, you'll never have to worry about running out of product again!
The printing apparatus includes a sending unit to send an order request for requesting an ordering apparatus to order a consumable in a case where a predetermined condition regarding the consumable of which the degree exceeds a predetermined degree is satisfied. The sending unit sends the order request based on information related to a current contract and the information related to the consumable in a case where a remaining contract period based on the contract expiration date of the current contract is equal to or more than a predetermined number of dates. Additionally, the sending unit sends the order request based on information related to a next contract in cases where the remaining contract period based on the contract expiration date of the current contract is less than or equal to predetermined number of dates.
US Patent 11498350
Hyundai Motor Company
Keep your ride soundless with this wheel!
What is this invention?
Vehicle wheel including wavelength tube member
A vehicle wheel may have a wavelength tube member
That can cancel out sound waves in a cavity between the rim and tire.
The wavelength tube member has a rim seating portion
Which is in surface contact with the external surface of the rim.
It also has a plurality of wavelength tube portions
Formed on the rim seating portion to make it complete.
Vehicle wheels are a key part of any car or truck, and they play an important role in reducing noise and vibration. One way to improve wheel performance is to include a wavelength tube member - a specialized component that can absorb sound waves emitted from the tires.This technology has been around for years, but it's now available on a much wider scale thanks to Hyundai Motor Company. Their Vehicle wheel including wavelength tube member may include spokes, cylindrical rim configured to connect both circumferential portions of the spokes, and wavelength tube member accommodated on the rim between the first and second circumferential portions of the spokes and configured to cancel sound wave generated in cavity formed between rim and tire. This combination allows you to reduce noise levels while driving without having to sacrifice performance.
A vehicle wheel may include a wavelength tube member that can cancel sound waves generated in a cavity between the rim and tire. The wavelength tube member may have a rim seating portion that is in surface contact with and accommodated on an external surface of the rim, and a plurality of wavelength tube portions formed on the rim seating portion.
US Patent 11498372
HYUNDAI MOTOR COMPANY
Keep your ride cool with a battery storage device
What is this invention?
Battery storage device for electric vehicle
There once was a battery device
That had a case that could be disposed
On the floor of a vehicle,
Which saved interior space.
The module could be cooled by using air,
Which simplified the cooling structure and saved cost.
There's a new battery storage device on the market that takes cooling to a whole new level - and it could be just what you need if you're in the market for an electric vehicle. Hyundai Motor Company's Battery Storage Device for Electric Vehicles (B-SDD EV) is designed to secure an interior space while providing easy access to your batteries. Not only does this system save you time and money, but it also helps reduce noise levels caused by other components in the car. Plus, since it blocks noise from flowing into the passenger compartment, you can rest assured that they'll stay comfortable during long drives.
The battery case of a battery storage device can be disposed on the vehicle floor, thereby securing an interior space. The battery module of the battery storage device can be cooled by using an interior air, thereby simplifying a cooling structure and saving a manufacturing cost. In addition, the battery storage device for an electric vehicle blocks noise generated by a cooling device and an electrical component from flowing into the interior, thereby preventing the occurrence of a passenger's discomfort feeling caused by the noise.
US Patent 11498404
Hyundai Motor Company
A Fuel Supply Valve That Supplies Fuel From A Fuel Tank To A Fuel Cell Stack Maintains Airtightness
What is this invention?
Fuel supply valve
There once was a fuel supply valve
That had a plunger, a core, and a block
The pressure chamber helped keep air inside
And prevented any leakage or stock
This valve was essential for the fuel cell stack
Hyundai Motor Company has invented a new fuel supply valve that will help improve the efficiency of fuel cells. This valve - known as the Fuel supply valve, - includes a plunger with a hollow inside, a core part disposed on top of the plunger, and a block part disposed within the hollow to maintain airtightness between the core part and the plunger. This space is then defined as a pressure chamber, which helps keep fuel cell stacks airtight and prevents leaks.
A fuel supply valve for supplying fuel from a fuel tank to a fuel cell stack includes: a plunger having a hollow therein, a core part disposed on the plunger, and a block part disposed within the hollow to maintain airtightness between the core part and the plunger, and a space in which the airtightness of the hollow has been maintained by the plunger, the core part, and the block part is defined as a pressure chamber. The pressure chamber helps to keep air inside of the space while preventing any leakage.
US Patent 11498415
HONDA MOTOR CO., LTD.
Ground Fault Detection Device Keeps Your Home Safe
What is this invention?
Ground fault detection device
There once was a device for detecting ground faults
It had a capacitor that operated as a flying one
With a switch and resistor in series connecting the battery's positive electrode side to one end of the capacitor
And a discharge circuit with at least one discharge capacitor
Its other end connected to the negative electrode side of the battery
With so many devices relying on electricity to function, it's important that you have a ground fault detection device (GFD) connected to your high-voltage battery in case of an emergency. The Honda Motor Company has just released the Ground Fault Detection Device - a capacitor that connects to your battery and monitors for any faults. This device is perfect for applications like electric vehicles, where safety is of the utmost importance.
The ground fault detection device includes a detection capacitor operating as a flying capacitor, a first switch and a first resistor connecting the positive electrode side of the high-voltage battery and one end of the detection capacitor in series, and a discharge circuit including at least a discharge capacitor. The discharging circuit has one end connected to the positive electrode side of the high-voltage battery and an another end connected to the negative electrode side of the high-voltage battery. The discharge circuit further includes: a fifth switch that connects one end of the discharge capacitor and the positive electrode side Y capacitor, and a second discharge resistor and an eighth switch that connect the another end of the discharge capacitor and the ground in series.
US Patent 11498425
HYUNDAI MOTOR COMPANY
Eco-Friendly Vehicle's Coasting Control Method Determines Closest and Target Events
What is this invention?
Eco-friendly vehicle and method of controlling coasting for the same
There once was a method for coasting
That was eco-friendly and smart;
It determined when deceleration
Would be most effective to start,
And set the closest event as the first candidate
If you're looking for a way to improve the eco-friendliness of your vehicle, you may want to check out Hyundai's new Eco-friendly Vehicle and Method of Controlling Coasting. This system allows drivers to control their coasting by determining which deceleration event is closest to the target speed - and then setting that event as the closest effective event. This makes it easier than ever before to stay on track while driving, without having to constantly adjust your speed.
The patent describes a method for controlling coasting in an eco-friendly vehicle. The method includes determining at least one effective event among deceleration events configured with a target speed in a forward driving path, setting a closest effective event based on the current position among the at least one effective event as a first candidate event, determining whether at least one second candidate event corresponding to an event needed to be followed is present among remaining effective events except for the first candidate event of the at least one effective event, and when the at least one second candidate event is present, determining a target event among the first candidate event and the second candidateevent in consideration of a control start point.
US Patent 11498430
Hyundai Motor Company
Aiming Lamp with Rotating Center Reduces Occupation Space
What is this invention?
Rotation center decoupling type aiming lamp and vehicle including the aiming lamp
There once was a type of lamp known as a rotation center decoupling,
Which was applied to vehicles with the goal of improving their coupling.
The lamp included an aiming device in which an axis was spaced apart,
At a distance of an adjustment height, from a reference line of an aim point axis.
The reflector could be attached to the aim point axis by means of a bracket,
Such that the rotation center adjusting the light radiation direction would be formed at a position above or ahead of the reference line.
Hyundai Motor Company has invented a new type of aiming lamp called a rotation center decoupling type aiming lamp. This lamp uses an aiming device that is operated as a rotation center of the reflector, which allows for more stable aim and reduces the occupation space required by the Aiming Device. In addition, this design also secures structural robustness while satisfying low-speed collision regulations. With this innovation, you can now enjoy improved accuracy and stability when aiming your vehicle's headlights - making night driving much easier!
The patent describes a rotation center decoupling type aiming lamp that is applied to a vehicle. The lamp includes an aiming device in which an aiming axis spaced apart from an aiming point reference line of an aiming point axis at a distance of an aiming adjustment height is operated as a rotation center of the reflector. The aimer angle is changed through the aim point axis to which the reflector is attached by a reflector bracket, such that the rotation center of the reflector adjusting a light radiation direction may be formed at a position above or ahead of the aim point reference line, thereby reducing an occupation space of the Aiming Device and securing stability of the Aiming Driving. In addition, sufficient rear shock absorption space may also be secured in the Aiming Lamp, thereby securing structural robustness while satisfying low-speed collision regulations
US Patent 11498477
Honda Motor Co., Ltd.
The New Electric Scooter with a Lighting System that Illuminates the Back of Riders and Sides
What is this invention?
Electric scooter lighting for improved conspicuity
There once was an electric scooter
With a lighting system that was super duper
It had a rear light to show the way
And side lights to make it all bright and gay
The onboard processor could communicate
With a smart phone docked on it, what a feat!
One of the biggest challenges when riding an electric scooter is keeping yourself safe and visible in traffic. With this in mind, Honda has come up with a lighting system that will make you stand out from the rest. The system includes a rear-mounted light that projects light upward and toward the front of the scooter to illuminate the back of a rider, as well as side lights that project light to illuminate the sides of the scooter. This combination of features allows you to see better while driving, and it can be configured to automatically illuminate or change effects in response to road or environmental conditions. In addition, it can be integrated with the braking system for signaling a slow down or stop. Finally, it can be controlled by communication between an onboard processor and a personal computing device such as a smart phone that can be docked on the scooter and provide display of information and a means of input.
This electric scooter has a lighting system that includes a rear mounted light that projects light upward and toward the front of the scooter to illuminate the back of a rider, and side lights that project light to illuminate the sides of a scooter. The lighting system employs a multi-faceted approach to vary intensity and effects for improved visibility in traffic. The light system can be configured to automatically illuminate or change effects in response to road or environmental conditions, or in response to existing or future roadway infrastructure such as autonomous traffic infrastructure or adaptive traffic control systems. The light system may also be integrated with the braking system for signaling a slow down or stop. The system may be controlled by communication between an onboard processor and a personal computing device such as a smart phone that can be docked on the scooter and provide display of information and a means of input.
US Patent 11498478
HONDA MOTOR CO., LTD.
Storage System Hidden in Rear Cargo Space
What is this invention?
Storage system for a vehicle and interior compartment of a vehicle having same
There once was a car with some space
In the back where you could store stuff with ease
With a storage system near the front end
You could keep your things safe and sound
And when you needed them, just open the lid!
With the growing popularity of SUVs and crossovers, it's no wonder that storage solutions for these vehicles are becoming increasingly popular. Honda has introduced a new storage system for rear-facing cargo spaces in vehicles - perfect for those who need a little extra space to store their belongings. The lid on this system can be opened or closed, depending on your needs, to allow access to the hidden storage space while keeping things hidden from view from the outside. This is a great option if you're looking for an easy way to store your belongings without having them visible from the outside - perfect for busy people who don't have time to stop at every convenience store along the way!
A storage system can be located at a front end of a vehicle's rear cargo space. The vehicle can include a rear opening at the rear end of the cargo space and a closure selectively opening and closing the rear opening. The storage system can include a front panel located at the front end of the rear cargo space and a lid. The front panel can include an outer surface facing the rear cargo space and a storage space recessed from the outer surface. The lid can be selectively placed in a closed state and an opened state with respect to the front panel such that when in the closed state, the lid conceals the storage space from view from outside of vehicle while still allowing access to stored items within. When in open state, lid exposes stored items within for easy retrieval.
US Patent 11498489
HYUNDAI MOTOR COMPANY
Locking apparatus keeps your seat belt secure
What is this invention?
Locking apparatus of seat belt buckle for vehicle
The locking apparatus on a seat belt buckle
Includes a sector gear bracket to be integrally coupled
To a rear pipe which is in turn coupled
To a seat cushion frame - all this so it's not mucked up!
The sector gear bracket has an arc-shaped locking hole
And a sector gear arranged as an internal gear;
A pole bracket is located at one side
Of the sector gear bracket, with a shaft part that passes through
The locking hole and the seat cushion frame before being integrally coupled
At the lower end to the buckle;
A lock gear is also arranged on the pole bracket as an external gear.
The Hyundai Motor Company has come up with a new locking apparatus for seat belts - and it's perfect for vehicles that have fold-down seats. The sector gear bracket is configured to be integrally coupled to a rear pipe which is then coupled to a seat cushion frame, and the sector gear bracket features an arc-shaped locking hole. This allows you to securely lock the buckle in place without having to use any tools - making it much easier than ever before. Plus, the pole bracket located at one side of the sector gear bracket provides extra stability when securing the buckle.
The locking apparatus of a buckle of a seat belt for vehicles includes a sector gear bracket configured to be integrally coupled to a rear pipe which is coupled to a seat cushion frame, wherein the sector gear bracket has: an arc-shaped locking hole; and a sector gear arranged along the locking hole as an internal gear; a pole bracket located at one side of the sector gear bracket, wherein the pole bracket has a shaft part which is configured to pass through the locking hole and the seat cushion frame and then be integrally coupled to a lower end of the buckle; and a lock gear arranged on the pole bracket as an external gear.
US Patent 11498516
Honda Motor Co., Ltd.
ECU Authentication Processes Keep Vehicles Operational
What is this invention?
Vehicle control system
There once was a system for authentication
Between different devices, it was quite effective
The first and second process units were ECUs
And they performed two different authentication processes
If the two authentications matched, then permission could be granted
For the vehicle to be maintained by the manufacturer
The Honda Vehicle Control System has been designed to help keep your car in good condition by ensuring that the authentication information is always up-to-date. The system includes a first authentication process unit and a second authentication process unit, both of which are located within the ECU (Electronic Control Unit). When it comes to authenticating users - be they maintenance staff or regular drivers - this system is incredibly efficient. Not only does it quickly verify the credentials of those who need access, but it also allows for authorized operations to take place even when the authentication information doesn't match. This means you can continue using your car without any worries - even if someone unauthorized tries to start it up!
The patent describes a system in which authentication is performed between different devices. The first authentication process unit and the second authentication process unit are both ECUs, and they perform two different authentication processes - a first authentication process for comparing information from the maintenance operator terminal and a user terminal, and a second authentication process for comparing information from the first authentication information registration unit and the second authentication information registration unit. If the two authentications match, then an operation permission can be granted to the vehicle so that it can be maintained by the manufacturer.
US Patent 11498522
HONDA MOTOR CO., LTD.
Control Your Parking With This Automatic System
What is this invention?
Parking assist system
The parking assist system is great,
It can control the screen and set the date,
When the number of candidates detected goes over the limit,
The control device will select them according to a rule,
And then display where they're parked on the plate.
Parking has always been a hassle - finding a spot, getting out, and finding your way back. But now there's a new solution on the market: an autonomous parking assist system. This system helps you find a space quickly and easily, without having to worry about driving or navigating. Simply set your target parking position using the control device, and the system will take care of the rest - moving your car autonomously to the chosen spot. Not only is this technology convenient - it's also eco-friendly! With fewer accidents caused by drivers struggling to find a parking spot, this system is sure to make life easier for everyone involved.
The parking assist system includes a control device that is configured to control screen display of a display device, to set a parking position candidate selected by an occupant as a target parking position, and to control an autonomous parking operation to autonomously move the vehicle to the target parking position. When a number of the parking position candidates detected by a parking position candidate detector exceeds a predetermined upper limit number, the control device selects, from among the detected parking position candidates, the upper limit number of parking position candidates to be displayed on the display device according to a predetermined rule. The display device displays the parked positions that have been selected.
US Patent 11498553
Hyundai Motor Company
Control your car's inertia with this easy guide!
What is this invention?
Vehicle and method of controlling the same
There once was a method for driving
That used inertial guidance instead.
With information on events like stops and decelerations,
It could control the shift stage to drive at the target.
In today's world, it is more important than ever to have accurate and efficient control over your vehicle. With the Vehicle and Method of Controlling the Inertial Driving of a Vehicle, Hyundai Motor Company has provided a solution that will help you achieve just that.This system allows you to enter into an inertial driving guidance mode - in which you are given information about upcoming events, such as stops, decelerations, or re-accelerations. Based on this information, you then determine the target shift stage that corresponds to these events. Finally, you perform a shift control operation to reach this target shift stage. This ensures that your vehicle remains in its desired path at all times, no matter what obstacles may be present.
The patent describes a method for controlling the driving of a vehicle using inertial guidance. The method includes obtaining information related to one or more events, such as a stop event, a deceleration event, or an acceleration event, and determining a target shift stage based on the information. The target shift stage is then used to perform a shift control in order to drive the vehicle at the target shift stage.
US Patent 11498568
International Business Machines Corporation
Vehicle software warns drivers of impending traffic incident
What is this invention?
Vehicle equipment for notification of traffic impacting events
There was a car that had some software,
That could assess the traffic situation.
It would determine if there was an event,
Likely to cause some congestion.
If so, it would print out a pattern,
In order to help with the navigation.
Vehicle equipment is becoming more and more important as the world becomes increasingly congested. Onboard vehicle software like this allows drivers to stay informed of potential traffic issues, and take action accordingly - whether that means printing out a notification or stopping for the day. By ensuring drivers are always aware of what's going on around them, we're making life a little bit easier for everyone involved.
The onboard vehicle software performs the following operations: (1) receiving situation assessment information pertaining to traffic; (2) determining whether the situation assessment information is indicative of an event likely to impact traffic; and (3) in response to determining that the situation assessment information is indicative of the event likely to impact traffic, sending a print command to a printer communicatively coupled to the control device instructing the printer to print a patterned layer of a coloring substance to a surface supporting the vehicle.
US Patent 11498569
HYUNDAI MOTOR COMPANY
Autonomous driving mode can be switched to manual when human driver is not looking
What is this invention?
Autonomous driving control method and device
There once was a driverless car
That could steer all on its own.
But if drivers were found
To be looking around,
The car would then switch to manual mode.
With the proliferation of self-driving cars, it is important to have a method for controlling these vehicles in case of emergency. Hyundai Motor Company has come up with an ingenious solution to this problem - a system that will automatically switch autonomous driving modes in the event that a human driver intervenes.This system works by determining whether a human driver is in a forward gaze state under an autonomous driving mode. If so, then the system sets a first steering wheel torque threshold and a first torque holding time, based on this information. In addition, it determines whether human driver intervention has occurred - i.e., if the person has taken their hands off the wheel or if they are looking away from the car's path. If either of these conditions is met, then the system switches to manual mode and allows the driver to take control again.This system represents an important advance for self-driving cars - one that will help ensure that they can operate safely even in cases where someone is present onboard. It also demonstrates Hyundai Motor Company's commitment to innovation and its dedication to providing superior customer service
The method for controlling autonomous driving in an autonomous vehicle includes determining whether a human driver is in a forward gaze state under an autonomous driving mode, setting a first steering wheel torque threshold and a first torque holding time, based on a result of determining whether the human driver is in the forward gaze state. If it is determined that human driver intervention has occurred, then the autonomous driving mode is switched to manual driving mode.
US Patent 11498590
Hyundai Motor Company
Side Sill Reinforcement Holds Up Against The Weather
What is this invention?
Structure of side sill rear portion of vehicle
There was an embodiment with a side sill
With an outer panel and inner panel still
Two reinforcement members were aligned
So that a portion of each extended beyond their respective panels
With the increasing popularity of SUVs and other large vehicles, it is essential that side sill rear portions are stiff enough to support the weight of these vehicles. Unfortunately, traditional methods of reinforcing side sill rear portions have been unable to meet this requirement, which has led to a number of safety issues.The Structure of Side Sill Rear Portion of Vehicle invention by Hyundai Motor Company solves this problem by introducing an outer panel coupled to an outer reinforcement member in a rear portion of the side sill, an inner panel coupled to an inner reinforcement member in the rear portion of the side sill, and an inner reinforcement member connected to an outer side of the inner panel so that a portion is connected to the outer reinforcement member. This structure ensures that both the outer and inner panels are strong enough to support the weight of a SUV or other large vehicle, while also providing flexibility in design - allowing for variations in shape without affecting strength.
An embodiment includes a side sill with an outer panel and an inner panel. The outer panel is coupled to the rear portion of the side sill, and the inner panel is coupled to the front portion of the side sill. There are two reinforcement members: one attached to the outer side of the outer panel, and one attached to the inner side of the inner panel. The reinforcement members are aligned so that a portion of each member extends beyond their respective panels.
US Patent 11498621
Hamilton Sundstrand Corporation
The New Way to Save Your Refrigerator - Heat It Up and Use the Vacuum!
What is this invention?
Refrigeration systems
This refrigerator system is quite a find,
It's easy to install and uses less power.
It's more efficient than other models out there,
And produces lower emissions overall.
With the advent of climate change, it is more important than ever to find ways to reduce our reliance on fossil fuels. One way that refrigeration systems can help achieve this goal is by using renewable energy sources to power their pumps. The Hamilton Sundstrand Corporation Refrigeration System uses a passive pump to generate a vacuum and transfer heat from the refrigerant flowing through the system to produce partially cooled refrigerant flow. This system not only reduces our dependence on fossil fuels, but it also helps keep your food cold - no matter where you are!
The refrigeration system can include a main flow circuit configured to flow a refrigerant therethrough and a heat input disposed in the main flow circuit and configured to receive heat and transfer the heat to the refrigerant in the main flow circuit to output heated refrigerant flow. The passive pump can be disposed in the main flow circuit downstream of the heat input, and can use the heated refrigerant flow to generate a vacuum at a pump port. The condenser can be disposed in the main flow circuit downstream of the passive pump, and can receive heat from the heated refrigerant flow and reject it to cool the heated refrigerant Flow. The outlet of the condenser can be upstream of the heat input.This refrigerator system has several advantages over other systems: it is easy to install, it uses less energy, it is more efficient, and it produces lower emissions.
US Patent 11498686
HAMILTON SUNDSTRAND CORPORATION
Redundant Electrochemical Systems Keep Your Vehicle Running Smoothly
What is this invention?
Redundant systems for vehicle critical systems
There once was a car with two devices
That redundantly produced gasses and power
So if one should fail
The other would prevail
And the car could keep running for hours
Vehicle critical systems can be crucial for keeping your car on the road, and with today's technology, redundancy is key. The Hamilton Sundstrand Corporation has invented a system that allows for electrochemical devices to generate power in two different modes - normal mode and backup mode. In normal mode, the device generates electricity needed for vehicle functions like braking and steering; however, if the second device fails, the first one will step in and provide power for critical vehicle systems. This ensures that even if one of your devices malfunctions, you'll still have enough juice to keep everything running smoothly.
Redundant electrochemical systems and methods for vehicles are described. The systems include a first electrochemical device located at a first position on the vehicle wherein the first electrochemical device is configured to generate at least one of inert gas, oxygen, and electrical power and a second electrochemical device located at a second position on the vehicle wherein the second electrochemical device is configured to generate at least one of inert gas, oxygen, and electrical power. The first electrochemical device is configured to operate in a first mode during normal operation of the vehicle and a second mode when the second electrochemical device fails, wherein in the second mode, the first electrochemical device provides the at least one of inert gas, oxygen, and electrical power for at least one vehicle critical system of the vehicle.
US Patent 11498691
Canon Kabushiki Kaisha
New Sheet Feeding Apparatus Allows Heating Unit to Attach Easily
What is this invention?
Sheet feeding apparatus and image forming apparatus
There was once a sheet feeding apparatus
That was configured to be attached to an image forming apparatus
It included a frame body and a locking member
Which was movable between a locking position and releasing position
In attaching the heating unit, the locking member restricted movement to the attaching position by interfering with the heating unit when located at the releasing position
Canon Kabushiki Kaisha has invented a new sheet feeding apparatus that is perfect for attaching heating units to image forming apparatuses. By allowing the locking member to move between the releasing and locking positions, this apparatus ensures that the heating unit will not interfere with its operation when it is attached - making installation a breeze. In addition, this system allows for easy movement of the heating unit between different attachment points on the frame body. Whether you're in need of extra heat or just want to save space, this innovative sheet feeding apparatus from Canon Kabushiki Kaisha is sure to meet your needs!
The disclosed sheet feeding apparatus is configured to be attached to an image forming apparatus. The sheet feeding apparatus includes a frame body and a locking member provided on an upper part of the frame body. The locking member is configured to be movable between a locking position where the frame body is locked to the image forming apparatus and a releasing position where the locking of the frame body is released. In attaching the heating unit to an attaching position of the frame body, the locking member is configured to restrict a movement of the heating unit to the attaching position by interfering with the heating unit when the locking member is located at the releasing position and to allow a movement of the heating unit to the attaching position whenthe locking member is located atthelockingposition.
US Patent 11498786
CANON KABUSHIKI KAISHA
Slow Sheet Conveyance For Sticky Notes
What is this invention?
Sheet conveyance apparatus, document reading apparatus and image forming apparatus
There once was a sheet conveyance machine
That had two detection sensors, as seen.
One day, when in mode one,
Both sensors detected no sheet--
The conveyor then went into standby mode!
With so many different types of documents out there, it can be hard to keep track of which one you're trying to read. That's where a sheet conveyance apparatus comes in - this device allows you to easily transport sheets of paper from one place to another. Not only is this an incredibly useful tool for office workers and home-owners, but it's also great for businesses who need to send large batches of documents quickly and efficiently.In the Sheet conveyance apparatus described above, first and second detection sensors are located at different positions on the sheet supporting tray - allowing you to automatically determine which direction the sheet is going in. This system is controlled by a control unit, which makes sure that the sheet conveyance speed remains consistent no matter what happens with the detection sensors. So whether you're reading a document or just moving some papers around, this machine will make your life a lot easier!
The sheet conveyance apparatus includes a sheet supporting tray to support a sheet, a sheet conveyance unit to convey the sheet supported on the sheet supporting tray, first and second detection sensors to detect the supported sheet at first and second detection positions farther from a center of the sheet supporting tray in a Sheet Width Direction than the first detection position. In addition, a control unit controls the sheet conveyance unit in either of two modes: (1) A mode where if both of the first and second detection sensors detect the supportedsheet at their respective positions then the control unit will operate the Sheet Conveyance Unit in Mode 1; however if only one of them detects it then it will operate in Mode 2 which is slower than Mode 1. (2) A Second mode where if both detectors detect that there is nosupportedsheet present at their respective positions then they will go into standby mode until another detected object comes along.
US Patent 11498788
